Does Phase Matter For Monaural Source Separation?

Does Phase Matter F or Monaural Sour ce Separation? Mohit Dubey Oberlin College and Conserv atory mdubey@oberlin.edu Garrett K enyon Los Alamos National Laboratory gkenyon@lanl.gov Nils Carlson New Me xico Institute of Mining and T echnology nils.carlson@student.nmt.edu A ustin Thresher New Me xico Consortium athreshe@gmail.com Abstract The "cocktail party" problem of fully separating multiple sources from a single channel audio wa veform remains unsolved. Current biological understanding of neural encoding suggests that phase information is preserved and utilized at ev ery stage of the auditory pathway . Ho wev er , current computational approaches primarily discard phase information in order to mask amplitude spectrograms of sound. In this paper , we seek to address whether preserving phase information in spectral representations of sound provides better results in monaural separation of vocals from a musical track by using a neurally plausible sparse generati ve model. Our results demonstrate that preserving phase information reduces artifacts in the separated tracks, as quantified by the signal to artifact ratio (GSAR). Furthermore, our proposed method achie ves state-of-the-art performance for source separation, as quantified by a mean signal to interference ratio (GSIR) of 19.46. 1 Introduction The "cocktail party problem" - isolating a sound-stream of interest from a complex or noisy mixture - remains one of the most important unsolved problems in signal processing. While it is well understood that the human (mammalian) auditory system is an expert at solving this problem, ev en without binaural or visual cues, it is still unclear how a similar solution can be implemented computationally . In biological systems, it is understood that bottom-up grouping of similar sounds (harmonic stacks), top-down attention to wards sounds of interest ("v oice" vs. "guitar"), as well as amplitude fluctuations of sounds in similar frequency bands (vibrato/tremolo) are all useful processes for blind monaural source segre gation [1]. The e xtreme degree of ov ercompleteness of the auditory cortex when compared to the cochlea implies that sparse encoding of auditory information is another key part of the neural solution [2]. Current understanding of neural auditory encoding consists of two distinct theories: "place theory" and "volle y theory". In place theory , different frequencies of sound are encoded in different physical locations, as seen in the spectral tuning of the cochlea and the resulting tonotopic map that propagates all the way up to the primary auditory cortex (A1) [3]. In volley theory , the frequency and phase of a sound wa ve are encoded by neuronal spik es that coincide with a regular point on that wa ve, a process known as "phase-locking" [4]. Research on the mammalian auditory pathway has shown that "phase locking" in the auditory nerve can operate at frequencies up to 4 - 6 kHz (depending on the animal) and is preserved throughout the auditory pathway to A1 at frequencies up to ~200 Hz, allo wing for phase-locking to the fundamental frequencies of the human voice and many musical instruments [5]. The preservation of phase information throughout the auditory path is useful in binaural source separation as well as speech processing, as A1 cortical neurons ha ve been 31st Conference on Neural Information Processing Systems (NIPS 2017), Long Beach, CA, USA. shown to phase-lock to a sequence of phonemes [5] [6]. A1 cortical neurons in cats hav e also been shown to con ve y more abstract auditory information than structured spectro-temporal pat- terns, implying that A1 receptive fields are comple x and well tuned for monaural source separation [7]. In recent years, multifarious computational approaches have tried to solve the blind monaural cocktail party problem including robust PCA [8], Recurrent Neural Netw orks [9], Con volutional Denoising Autoencoders [10], and Non-Negati ve Matrix Factorization [11]. A large majority of these implementations separate sources by using some form of "masking" of amplitude power spectra, discarding all phase information from the original sound during training [12] and only preserving time-frequency bins that (up to some threshold) contain the source of interest. A recent work utilizing a Fully Complex Deep Neural Network (FDCNN) has sho wn that preserving both the real and imaginary parts of the Fourier representations of musical sound during training provides better results compared to a non-complex DNN, especially when a sparseness penalty is also employed [13]. While the current literature has provided insight into discriminative modeling for monaural source separation, it is still not clear whether preserving phase information (as the brain does) assists in learning the underlying generators of distinct sound sources in a sparse encoding. The idea of sparse approximation is based on the principle that the brain uses as fe w activ e neurons as possible to represent a signal as accurately as possible. It has been shown that by learning sparse representations of static images or movies, networks con ver ge on features similar to the receptiv e fields of simple cells in the primate primary visual cortex [14] [15] [16]. Analogously , one might expect to learn features similar to the spectrotemporal recepti ve fields present in the primary auditory cortex when learning on phase-rich spectrotemporal representations of auditory input. This analogy has been e xplored using the locally competiti ve algorithm (LCA) on time-dependent power spectral and cochlear representations of speech and music with the resulting features ex- hibiting many of the properties of physiological receptive fields [17] including phase information [18]. In this paper we demonstrate that preserving phase information in learning a sparse generativ e model of musical data results in better separation of v ocals from a musical track. W e trained three sparse representations on musical audio using a con volutional locally competitive sparse coding algorithm using PetaV ision (https://github .com/PetaV ision): one preserving phase, two discarding phase. W e judged the relati ve success of the results on the source separation task based on the SDR (Signal-to-Distortion), SIR (Signal-to-Interference), and SAR (Signal-to-Artifact) ratios [19]. 2 Methods Our models were trained using the MIR-1K dataset [20] which consists of 1000 song clips ranging from 4 to 16 seconds sampled at 16 kHZ. The clips are taken from recordings of male and female amateur singers singing along to 110 Chinese karaoke tracks. The vocal and non-vocal tracks are stored in separate stereo channels, making the dataset ideal for monaural source separation studies. For this study , we shortened all of the clips to 2 seconds for computational ease. The dataset was divided into 950 training and 50 testing examples which were both randomly sorted, such that multiple male and female singers were present throughout. For the resultant training and testing sets, single channel mixtures were created with the vocals and non-vocals mix ed equally and sampled at 16 kHZ. Spectral representations of the vocals, non-vocals, and mixtures for both train and test sets were generated using a 512 point short time Fourier transform (STFT) with 50 percent o verlap and a Hanning Windo w , resulting in 256 independent frequency bins up to 8 kHz and 128 time bins. Phase information (both real and imaginary parts) were stored in one case, while only the modulus amplitude was stored in the other (no phase information). Logically , the phase rich representations contain twice the amount of information as the representation without phase. T o av oid this bias, a third pair of train and test sets was also generated without phase information using the same short time F ourier transform (STFT) but with twice the number of independent frequency bins (512). 2 All three datasets of vocal and non-vocal mixtures were then trained identically using the Locally Competitiv e Algorithm (LCA), which functions by minimizing the error between input and reconstruction while also minimizing the activity of elements used in the representation. This is expressed mathematically as the minimization of an ener gy function, E ( − → I , φ , − → a ) = min { − → a , φ }  1 2 || − → I − φ − → a || 2 + λ || − → a || 1  (1) where − → I represents the input, − → a represents acti vation v alues for the basis v ectors φ , and λ represents the threshold or "sparsity penalty". Approximate minimization of the energy function for a giv en two second "sound image" is accomplished by numerically solving the ordinary dif ferential equation that results from taking the partial deriv ativ e of the energy with respect to activation coefficients, while a minimum of the energy function with respect to the basis vectors is accomplished by iterativ e stochastic gradient descent using a local Hebbian rule with momentum. In order to obtain a more neurally plausible network, our implementation deploys horizontal competition between elements in the hidden layer, by inserting membrane potentials u such that − → a = T ( u ) , where T ( u ) is a soft-threshold function, and du dt is the deriv ati ve of the energy function with respect to the acti vation coefficients (as in Rozell et al. [16]) . T o locate the optimum threshold for our datasets, we first trained our network for two epochs on the mixed training set (phase only) at multiple threshold v alues. W e then added Gaussian noise to the training set and used the resulting sparse codes to denoise the data. Through this method, we found that the optimum threshold for our network w as around .625, resulting in average sparsity of approximately 2.8 percent (see Figure 1). Figure 1: Normalized denoising error for v arious thresholds (labeled) plotted by av erage sparsity . Each network was trained for four epochs on the respecti ve training set (Phase, No Phase, No Phase x2) using a display period of 1000 timesteps, a dictionary size of 8192 features (2x o vercomplete) and stride of 2. Each feature represented the entire frequency dimension and 128 ms of sound. The resultant dictionaries were used to write out sparse codes for the training and testing sets of the three mixtures. Once sparse codes were generated for the three datasets, a linear classifier was implemented in Petavision to separate out vocals and non-vocals from the mixtures. The classifier was initialized with the features trained during the sparse coding procedure and allowed to adapt for 40 epochs through the training set. All other parameters including the threshold and learning rate were held 3 T able 1: Results on T est Set Run GSIR GSAR GNSDR Phase 12 . 12 ± 9 . 12 − 3 . 51 ± 5 . 92 1 . 49 ± 3 . 02 No Phase 12 . 76 ± 12 . 07 − 9 . 72 ± 4 . 36 1 . 35 ± 4 . 01 No Phase x 2 14 . 84 ± 13 . 26 − 10 . 95 ± 4 . 50 1 . 86 ± 3 . 88 Denoised 19 . 46 ± 8 . 61 2 . 88 ± 5 . 54 5 . 21 ± 2 . 77 constant from the sparse coding procedure. The resulting features were used to separate v ocals and non-vocals on the three testing sets and the resulting stems were used to calculate the GSIR, GSAR, and GNSDR, as shown in [8]. A fourth set of stems were generated by running the phase-rich results through the classifier again to denoise the separated v ocal and non-vocal tracks, pro viding the best possible results for our blind monaural source separation technique (Denoised). 3 Results Performance results for each of the datasets are pro vided in T able 1. GSIR measures the remaining interference between the sources, GSAR indicates the artifacts caused by the separation algorithm and GNSDR measures ho w distorted the separated sources are and is considered the o verall perfor - mance ev aluation for source separation. While it is clear that GNSDR and GSIR show no general improv ements with phase information included, the GSAR is noticeably higher for the phase results. This implies that including phase information introduces fewer artifacts during the source separation process, e ven when more frequency bins are used to account for the loss of information. Furthermore, our mean SIR v alue of 19.46 for the denoised audio indicates very high separation quality that is state of the art compared to other published methods [8][12][13]. V ocals Non-V ocals Original Phase No Phase Figure 2: Spectrograms of non-vocals and v ocals for phase and no-phase of a sample from the test set. While phase reconstructs less high-frequencies, no-phase adds energy in spurious places (artif acts). 4 Conclusion Using a generativ e sparse coding model we have demonstrated that preserving phase information results in fe wer artifacts on musical source separation tasks. In addition, we ha ve introduced a ne w method for separating musical sources that achie ves state of the art separation quality . In the future, we plan to run source separation experiments on other auditory data (speech, instrumental music, etc.) as well as e xplore the benefits of hierarchical sparse coding in source separation. Acknowledgments This work was funded by NSF and the D ARP A UPSIDE program. 4 References [1] McDermott, J. H. (2009). "The cocktail party problem." Current Biology , 19(22), 1024-1027. Retriev ed June 8, 2017. [2] Chechik, Gal, Michael J. Anderson, Omer Bar-Y osef, Eric D. Y oung, Naftali T ishby , and Israel Nelken. "Reduction of Information Redundancy in the Ascending Auditory P athway ." Neuron 51 (2006): 359-68. Print. [3] Oxenham, A. J. (2013). "Revisiting place and temporal theories of pitch." Acoustic Science and T echnol- ogy ,34(6), 388-396. [4] Joris, P . X. (2004). "Neural Processing of Amplitude-Modulated Sounds." Physiological Revie ws, 84(2), 541-577. doi:10.1152/physrev .00029.2003 [5] Nourski, K. V ., and Brugge, J. F . (2011). "Representation of temporal sound features in the human auditory cortex." Re views in the Neurosciences, 22(2). doi:10.1515/rns.2011.016 [6] W ang, R., Perreau-Guimaraes, M., Carvalhaes, C., and Suppes, P . (2012). "Using phase to recognize English phonemes and their distincti ve features in the brain." Proceedings of the National Academy of Sciences of the United States of America, 109(50), 20685-20690. http://doi.org/10.1073/pnas.1217500109 [7] Chechik, G., and Nelken, I. (2012). "Auditory abstraction from spectro-temporal features to coding auditory entities." Proceedings of the National Academy of Sciences of the United States of America, 109(46), 18968- 18973. http://doi.org/10.1073/pnas.1111242109 [8] P . S. Huang, S. D. Chen, P . Smaragdis and M. Hasegaw a-Johnson, "Singing-voice separation from monaural recordings using rob ust principal component analysis," 2012 IEEE International Conference on Acoustics, Speech and Signal Processing (ICASSP), Kyoto, 2012, pp. 57-60. doi: 10.1109/ICASSP .2012.6287816 [9] P . S. Huang, M. Kim, M. Hasegawa-Johnson and P . Smaragdis, "Joint Optimization of Masks and Deep Recurrent Neural Networks for Monaural Source Separation," in IEEE/A CM T ransactions on Audio, Speech, and Language Processing, vol. 23, no. 12, pp. 2136-2147, Dec. 2015. Doi: 10.1109/T ASLP .2015.2468583 [10] Grais, E. M., and Plumbley , M. D. (2017). "Single Channel Audio Source Separation using Con volutional Denoising Autoencoders." ArXiv . Retrieved from https://arxi v .org/abs/1703.08019. [11] T . Barker and T . V irtanen, "Blind Separation of Audio Mixtures Through Nonnegati ve T ensor Factorization of Modulation Spectrograms," in IEEE/ACM T ransactions on Audio, Speech, and Language Processing, vol. 24, no. 12, pp. 2377-2389, Dec. 2016. [12] Simpson, A. J., Roma, G., and Plumble y , M. D. (2015). "Deep Karaoke: Extracting V ocals from Musical Mixtures Using a Con volutional Deep Neural Network." ArXi v . doi: [13] Y . S. Lee, C. Y . W ang, S. F . W ang, J. C. W ang and C. H. W u, "Fully complex deep neural network for phase-incorporating monaural source separation," 2017 IEEE International Conference on Acoustics, Speech and Signal Processing (ICASSP), New Orleans, LA, 2017, pp. 281-285. [14] B. Olshausen and D. Field, "Emergence of simple-cell recepti ve field properties by learning a sparse code for natural images," in Nature, vol. 681, p. 607-609, 1996. [15] B. Olshausen, "Highly ov ercomplete sparse coding." SPIE 2013 [16] C. Rozell, et al., "Sparse coding via thresholding and local competition in neural circuits," in Neural Computation, 2008. [17] Carlson NL, Ming VL, DeW eese MR (2012), "Sparse Codes for Speech Predict Spectrotemporal Receptive Fields in the Inferior Colliculus." PLoS Comput Biol 8(7): e1002594. doi:10.1371/journal.pcbi.1002594 [18] Dubey , M. L., Shultz, P . F ., and Ken yon, G. T . (2016, March). Learning phase-rich features from streaming auditory images. In Image Analysis and Interpretation (SSIAI), 2016 IEEE Southwest Symposium on (pp. 73-76). IEEE. [19] E. V incent, R. Gribonv al and C. Fev otte, "Performance measurement in blind audio source separation," in IEEE T ransactions on Audio, Speech, and Language Processing, vol. 14, no. 4, pp. 1462-1469, July 2006. doi: 10.1109/TSA.2005.858005 [20] Chao-Ling Hsu and Jyh-Shing Roger Jang, "On the Improvement of Singing V oice Separation for Monaural Recordings Using the MIR-1K Dataset," IEEE T rans. Audio, Speech, and Language Processing, volume 18, issue 2, p.p 310-319, 2010. 5
