Industry experience indicates that the ability to incrementally expand data centers is essential. However, existing high-bandwidth network designs have rigid structure that interferes with incremental expansion. We present Jellyfish, a high-capacity network interconnect, which, by adopting a random graph topology, yields itself naturally to incremental expansion. Somewhat surprisingly, Jellyfish is more cost-efficient than a fat-tree: A Jellyfish interconnect built using the same equipment as a fat-tree, supports as many as 25% more servers at full capacity at the scale of a few thousand nodes, and this advantage improves with scale. Jellyfish also allows great flexibility in building networks with different degrees of oversubscription. However, Jellyfish's unstructured design brings new challenges in routing, physical layout, and wiring. We describe and evaluate approaches that resolve these challenges effectively, indicating that Jellyfish could be deployed in today's data centers.
A well provisioned data center network is critical to ensure that servers do not face bandwidth bottlenecks to utilization; to help isolate services from each other; and to gain more freedom in workload placement, rather than having to tailor placement of workloads to where bandwidth is available [22]. As a result, a significant body of work has tackled the problem of building high capacity network interconnects [6, 17-20, 38, 42, 43].
One crucial problem that these designs encounter is incremental network expansion, i.e., adding servers and network capacity incrementally to the data center. Expansion may be necessitated by growth of the user base, which requires more servers, or by the deployment of more bandwidth-hungry applications. Expansion within a data center is possible through either planned overprovisioning of space and power, or by upgrading old servers to a larger number of more powerful but energyefficient new servers. Planned expansion is a practical strategy to reduce up-front capital expenditure [28].
Industry experience indicates that incremental expansion is important. Consider the growth of Facebook’s data center server population from roughly 30,000 in Nov. 2009 to >60,000 by June 2010 [34]. While Facebook has added entirely new data center facilities, much of this growth involves incrementally expanding existing facilities by “adding capacity on a daily basis” [33]. For instance, Facebook announced that it would double the size of its facility at Prineville, Oregon by early 2012 [16]. A 2011 survey [15] of 300 enterprises that run data centers of a variety of sizes found that 84% of firms would probably or definitely expand their data centers in 2012. Several industry products advertise incremental expandability of the server pool, including SGI’s Ice-Cube (marketed as “The Expandable Modular Data Center” [5]; expands 4 racks at a time) and HP’s EcoPod [24] (a “pay-as-you-grow” enabling technology [23]).
Do current high-bandwidth data center network proposals allow incremental growth? Consider the fat-tree interconnect, as proposed in [6], as an illustrative example. The entire structure is completely determined by the port-count of the switches available. This is limiting in at least two ways. First, it makes the design space very coarse: full bisection bandwidth fat-trees can only be built at sizes 3456, 8192, 27648, and 65536 corresponding to the commonly available port counts of 24, 32, 48, and 641 . Second, even if (for example) 50-port switches were available, the smallest “incremental” upgrade from the 48-port switch fat-tree would add 3,602 servers and would require replacing every switch.
There are, of course, some workarounds. One can replace a switch with one of larger port count or oversubscribe certain switches, but this makes capacity distribution constrained and uneven across the servers. One could leave free ports for future network connections [14,20] but this wastes investment until actual expansion. Thus, without compromises on bandwidth or cost, such topologies are not amenable to incremental growth.
Since it seems that structure hinders incremental expansion, we propose the opposite: a random network in-terconnect. The proposed interconnect, which we call Jellyfish, is a degree-bounded2 random graph topology among top-of-rack (ToR) switches. The inherently sloppy nature of this design has the potential to be significantly more flexible than past designs. Additional components-racks of servers or switches to improve capacity-can be incorporated with a few random edge swaps. The design naturally supports heterogeneity, allowing the addition of newer network elements with higher port-counts as they become available, unlike past proposals which depend on certain regular portcounts [6, 18-20, 38, 42]. Jellyfish also allows construction of arbitrary-size networks, unlike topologies discussed above which limit the network to very coarse design points dictated by their structure.
Somewhat surprisingly, Jellyfish supports more servers than a fat-tree [6] built using the same network equipment while providing at least as high per-server bandwidth, measured either via bisection bandwidth or in throughput under a random-permutation traffic pattern. In addition, Jellyfish has lower mean path length, and is resilient to failures and miswirings.
But a data center network that lacks regular structure is a somewhat radical departure from traditional designs, and this presents several important challenges that must be addressed for Jellyfish to be viable. Among these are routing (schemes depending on a structured topology are not applicable), physical construction, and cabling layout. We describe simple approaches to these problems which suggest that Jellyfish could be effectively deployed in today’s data centers.
Our key contributions and conclusions are as follows:
• We propose Jellyfish, an incrementally-expandable, high-bandwidth data center interconnect based on a rando
