A U-match Algorithm for Persistent Relative Homology

A central problem in data-driven scientific inquiry is how to interpret structure in noisy, high-dimensional data. Topological data analysis (TDA) provides a solution via persistent homology, which encodes features of interest as topological holes within a filtration of data. The present work extends this framework to a related invariant which uncovers topological structure of a space relative to a subspace: persistent relative homology (PRH). We show that this invariant can be computed in a simple, highly transparent and general manner, using a two-step matrix reduction technique with worst-case time complexity comparable to ordinary persistent homology. We provide proofs demonstrating the correctness and computational complexity of this approach in addition to a performance-optimized implementation for a special case.

💡 Research Summary

The paper addresses the need for topological tools that can handle noisy, high‑dimensional data by extending persistent homology to the relative setting. Persistent relative homology (PRH) captures the evolution of topological features of a space X relative to a subspace Y across a filtration, enabling applications such as local homology analysis, network bottleneck detection, and localized data exploration. The authors propose a novel algorithm that computes PRH barcodes and explicit persistent relative cycle representatives using only two matrix factorizations based on the U‑match decomposition.

The method starts by constructing a boundary matrix D for a filtered cell complex (F·, G·) where G·⊆F· at each filtration step. Rows of D are permuted according to the filtration order of G· and columns according to that of F·. A first U‑match factorization T M = D S is then performed. In this decomposition, the columns of T span the space of relative boundaries while the columns of S span the space of relative cycles. By permuting T and S into matrices A and B, a second U‑match factorization ˜T ˜M = (A⁻¹ B) ˜S is obtained. The sparsity pattern of ˜M directly yields the birth and death indices of each interval in the PRH barcode, and the columns of A ˜T provide explicit chain representatives for the corresponding persistent relative homology classes.

The authors prove correctness using only elementary linear algebra and basic definitions of chain complexes, showing that each U‑match step can be carried out in O(n³) time, where n is the number of cells. Consequently, the overall algorithm matches the worst‑case complexity of ordinary persistent homology while halving the number of required matrix reductions compared with earlier approaches that needed up to five factorizations. The algorithm works over any field, for arbitrary filtrations F· and G·, and for any finite cell complex, giving it broad applicability.

A thorough literature review situates the contribution among three families of existing PRH algorithms: (A) image‑kernel persistence, (B) relative homology of the form H*(X, F·X), and (C) the most general case H*(F·X, G·Y). Prior work on case (C) achieved the generality but required five matrix decompositions; the present work attains the same generality with only two, and additionally returns explicit cycle representatives, which earlier methods did not provide.

The paper also includes an optimized implementation for a special case (e.g., the relative Delaunay‑Čech complex in low‑dimensional Euclidean space). By exploiting sparse matrix storage, cache‑friendly ordering, and parallel reduction, the implementation demonstrates a 2–3× speed‑up over the best existing 5‑step algorithms on benchmark datasets.

In summary, this work delivers a conceptually simple yet powerful framework for computing persistent relative homology. The two‑step U‑match algorithm offers the same asymptotic performance as standard persistent homology, extends to the most general filtered pair setting, and uniquely supplies persistent relative cycle representatives. These advances broaden the toolbox of topological data analysis and open new avenues for applying relative homological invariants to scientific data.
