Asymptotic windings, surface helicity and their applications in plasma physics

In [J. Cantarella, J. Parsley, J. Geom. Phys. 60:1127 (2010)] Cantarella and Parsley introduced the notion of submanifold helicity. In the present paper we investigate properties of surface helicity and in particular answer two open questions posed in the aforementioned work: (i) We give a precise mathematically rigorous physical interpretation of surface helicity in terms of linking of distinct field lines. (ii) We prove that surface helicity is non-trivial if and only if the underlying surface has non-trivial topology (i.e. at least one hole). We then focus on toroidal surfaces which are of relevance in plasma physics and express surface helicity in terms of average poloidal and toroidal windings of the individual field lines of the underlying vector field which enables us to provide a connection between surface helicity and rotational transform. Further, we show how some of our results may be utilised in the context of coil designs for plasma fusion confinement devices in order to obtain coil configurations of particular “simple” shape. Lastly, we consider the problem of optimising surface helicity among toroidal surfaces of fixed area and show that toroidal surfaces admitting a symmetry constitute global minimisers.

💡 Research Summary

The paper develops a rigorous theory of “surface helicity,” a two‑dimensional analogue of the classical three‑dimensional helicity that measures the average linking of magnetic or vortex field lines. Starting from the sub‑manifold helicity introduced by Cantarella and Parsley, the authors first define a surface Biot–Savart operator (BS_{\Sigma}) acting on tangent vector fields on a closed, connected (C^{1,1}) surface (\Sigma). For a vector field (v) in the space (L^{4/3}V(\Sigma)) the surface helicity is defined as (H(v)=\int_{\Sigma} v\cdot BS_{\Sigma}(v),d\sigma). This functional is continuous and bounded by the (L^{4/3}) norm of the field.

The first major result (Theorem 2.4) shows that the (0,2,3)‑helicity of the closed 1‑form (\iota_{v}\omega_{\Sigma}) (the contraction of the area form with (v)) coincides exactly with the vector‑field helicity (H(v)). Consequently, surface helicity inherits the physical interpretation of ordinary helicity: it is the average linking number of distinct field lines.

The second key theorem (Theorem 2.5) establishes a topological criterion: surface helicity is non‑trivial if and only if the surface has non‑zero genus. If (\Sigma) is a sphere ((g=0)), every divergence‑free tangent field has zero helicity; if (g\ge1) there exist divergence‑free fields with non‑zero helicity. Moreover, any co‑exact field (of the form (\nabla_{\Sigma}f\times N)) has zero cross‑helicity with every other divergence‑free field, emphasizing the role of topology rather than exact differential structure.

To give a concrete physical picture, the authors construct a linking‑number representation (Theorem 2.6). For a given field line segment (\gamma_x:
