AutoMOS: Learning a non-intrusive assessor of naturalness-of-speech

A utoMOS: Lear ning a non-intrusiv e assessor of naturalness-of-speech Brian Patton bjp@google.com Y annis Agiomyrgiannakis agios@google.com Michael T erry michaelterry@google.com Ke vin W ilson kwwilson@google.com Rif A. Saurous rif@google.com D. Sculley dsculley@google.com Abstract De velopers of text-to-speech synthesizers (TTS) often make use of human raters to assess the quality of synthesized speech. W e demonstrate that we can model human raters’ mean opinion scores (MOS) of synthesized speech using a deep recurrent neural network whose inputs consist solely of a ra w wa veform. Our best models provide utterance-level estimates of MOS only moderately inferior to sampled human ratings, as sho wn by Pearson and Spearman correlations. When multiple utterances are scored and av eraged, a scenario common in synthesizer quality assessment, AutoMOS achiev es correlations approaching those of human raters. The AutoMOS model has a number of applications, such as the ability to explore the parameter space of a speech synthesizer without requiring a human-in-the-loop. 1 Introduction T o ev aluate changes to text-to-speech (TTS) synthesizers, human raters are often employed to assess the synthesized speech. Multiple human ratings of an audio sample contribute to a mean opinion scor e (MOS). MOS has been crowdsourced with specific attention to rater quality by [ 12 ]. While crowdsourcing introduces a de gree of parallelism to the rating process, it is still relativ ely costly and time-consuming to obtain MOS for TTS quality testing. Numerous systems hav e been produced to algorithmically produce objective assessments of audio quality approximating the subjective human assessment, including some which assess speech quality . For e xample, MCD [ 8 ], PESQ [ 13 ] and POLQA [ 6 ] target this particular space. These are intrusive assessors in that they assume the presence of an undistorted reference signal to facilitate comparisons when deriving ratings, something that does not e xist in the case of the synthesized speech of TTS. Non- intrusive assessments such as ANIQUE [ 7 ], LCQA [ 3 ] and P . 563 [ 9 ] hav e been proposed to ev aluate speech quality where this reference signal is not av ailable. Much research in quality assessment is targeted at telephon y , with emphasis on detecting distortions and other artifacts introduced by lossy compression and transmission. Throughout this work, a synthesizer constitutes a snapshot of the ev olving implementation of a unit selection synthesis algorithm and a continually gro wing corpus of recorded audio, combined with a specific set of synthesis/cost parameters. When we partition or aggregate data by synthesizer , we take all utterances from a giv en synthesizer and allocate them en masse to a single training or e v aluation fold, or to a single aggregate metric, e.g. synthesizer-le vel mean MOS . In [ 10 ], the authors used human ratings to improv e the correlation between MOS and unit selection TTS cost. Similarly , [ 1 , 11 ] explore means of tuning cost functions to incorporate subjectiv e preferences. Such works consider direct optimization of synthesizer MOS as a function of synthesizer parameters (e.g. cost function weights). In prior unpublished work we trained similar models and 30th Conference on Neural Information Processing Systems (NIPS 2016), Barcelona, Spain. Figure 1: Diagram of the best performing AutoMOS network found they could exceed 0.9 Spearman rank correlation between true and estimated synthesizer MOS. Howe v er , any modifications to parameter semantics or engine internals render this mapping in v alid. It is desirable to learn a synthesizer assessment which operates independently of engine internals, directly assessing pools of TTS wa veforms. W e demonstrate that deep recurrent networks can model natur alness -of-speech MOS ratings produced by human raters for TTS synthesizer ev aluation, using only ra w audio wav eform as input. W e e xplore a variety of deep recurrent architectures, to incorporate long-term time dependencies. Our tuned AutoMOS model achie ves a Spearman rank correlation of 0.949, ranking 36 dif ferent synthesizers. (Sampling a single human rating for each utterance yields a Spearman correlation of 0.986.) When ev aluating the calibration of AutoMOS on multiple utterances with similar predicted MOS, we find fi ve-fold median correlations > 0.9 and MSE competiti ve with sampled human ratings, ev en when we quantize the predicted utterance MOS to the 0.5 increments of the human rater scale. Such results open the door for scalable, automated tuning and continuous quality monitoring of TTS engines. 2 Model & Results Because audio data is of varying length for each example, either directly pooling across the time dimension or the use of recurrent neural networks (RNN) is suggested. T o encode the intuition that valuable information exists at relati vely lar ge time-scales (consider phone or transition duration or inflection, which may vary according to conte xt), we opt to explore a family of RNN models. In particular , we test a family of models that layer one or more fully-connected layers atop the time- pooled outputs of a stack of recurrent Long Short-T erm Memory [LSTM; 4 ] cells. The timeseries input to the LSTM is either a log-mel spectrogram or a time-pooled con volution as in [ 5 ], in each case over a 16kHz wav eform. W e consider the addition of single frame velocity and acceleration components to this timeseries. The final LSTM layer’ s outputs are max-pooled across time, and fed as inputs to the fully-connected hidden layers which compute final regression values. W e explored a means of inducing learning across longer timeframes (a stacked LSTM where deeper layers use a stride of 2 or more timesteps ov er the outputs of of lower -lev el LSTM layers), but found performance comparable to that of a simpler stacked or single-layer LSTM. Max-pooling non-final LSTM layers’ outputs and adding skip connections to the final hidden layers was not found to improv e performance. W e explore multiple modes of predicting and training over input wav eforms x : (1) predict sufficient statistics µ ( x ) , σ ( x ) and train on log-likelihood of indi vidual human ratings r i un- der Gaussian log p ( r i | µ ( x ) , σ ( x )) , (2) predict M O S ( x ) and train on utterance-level L2 loss ( M O S ( x ) − M O S true ) 2 , and (3) predict log its ( x ) and train on cross-entropy between the true 9-category distrib ution of human ratings and Cat( log its ( x )) per-utterance. W e train a separate set of outputs with a learned embedding of the ground-truth synthesizer , providing both regularization and gradients to the training process. Embeddings are initialized randomly; both the embedding and the prediction thereof recei ve a gradient (to ward each other) in each training step. The best performing model is illustrated in Figure 1. 2 T able 1: Model Hyperparameters Description Range explored Best Performer (Pearson r = 0.61) Learning rate; decay / 1000 steps 0.0001 - 0.1; 0.9 - 1.0 0.057; 0.94 L1; L2 regularization 0.0 - 0.001 1.4e-5; 2.6e-5 Loss strategy L2 | cross-entropy cross-entropy Synthesizer regression embedding dim 0 - 50 37 T imeseries type log-mel | pooled con v1d log-mel T imeseries width (# mel bins, conv filters) 20 - 100 86 T imeseries 1-step deriv atives (none) | vel. | vel. + acc. vel. + acc. LSTM layer width; depth 20 - 100; 1 - 10 93; 2 LSTM timestep stride at non-0th layers 1 - 10 10 LSTM layers feeding hidden layer inputs all | last all Post-LSTM hidden layer width; depth 20 - 200; 0 - 2 60; 1 All models were trained with Adagrad on batches of 20 examples asynchronously across 10 workers. W e use five-fold cross-validation to e valuate the best found set of hyperparameters, with all utterances for any gi ven synthesizer appearing exclusi vely in a single fold. Data W e use a corpus of TTS naturalness scores acquired ov er multiple years across multiple instances of quality testing for Google’ s TTS engines. All tests are iterations on a single English (US) voice used across multiple products. Raters scored each utterance gi ven a 5-point Likert scale for naturalness, in half-point increments. W e partition training data from holdout data such that all utterances for a giv en synthesizer are in the same partition. The data includes 168,086 ratings across 47,320 utterances generated by 36 synthesizers. The utterance quantity per synthesizer v aries from 64 to 4800: , in log-scale. Hyperparameter T uning W e used Google Cloud’ s HyperT une to explore a set of hyperparameters sho wn in T able 1. About 2 in 3 top-performing tuning runs used the cross-entropy categorical training mode. The top 10 configurations we found had ev al-set Pearson correlations between utterance-lev el predicted and true MOS ranging from 0.56-0.61 after 20,000 training steps. When we constrained the search space to those models using con v olution+pooling based timeseries (as opposed to log-mel), we found weaker best ev al-set correlations around 0.48. This could indicate there is little value in the sample-lev el details when dealing in synthesized speech, or could signal insufficient training data. While [ 14 ] reported gammatone-like learned filter banks, their speaker-independent ASR cov ers a much wider range of voices, and we did not observe a similar set of emer gent filters from random initialization. Initialization with gammatone filters yielded only nominal improv ements in performance (r=0.51). Relativ e to a simple L2 loss to the true MOS, we observed little benefit from training a Gaussian predictor against individual ratings. The estimated variance was typically higher than the true sample variance for a given utterance. Using a simpler L2 loss against the true MOS provided for faster training and con ver gence, allo wing us to try a wider variety of structural changes. T reating predictions as categorical and using a cross-entropy loss slightly outperformed the L2 construction in the top tuning runs (0.61 categorical vs. 0.58 L2). The categorical form gi ves AutoMOS more weights and hence a greater capacity near the output layer . Evaluation As simple baselines for comparison, we consider (1) a bias-only model which always predicts the mean of all observed utterances’ MOS and (2) a small nonlinear model which takes only utterance length as input (two 10-unit hidden layers with rectified linear acti vation), with the intuition that a longer utterance includes more opportunities to make mistakes deemed unnatural. W e draw one human rating for each utterance and show this comparison as a "Sample human rating" column. If errors are unbiased, an increased sample size should reduce error . W e sort utterances by predicted MOS and ev aluate correlations between E g r oup ( M O S predicted ) and E g r oup ( M O S true ) (where E is the expected v alue operator) on groupings of 10 or more utterances with adjacent predicted MOS in a similar fashion to a calibration plot. W e show such plots in Figure 2. 3 Figure 2: Left: Calibration plots (including all ev al folds of AutoMOS): Green represents perfect calibration; blue plots ( E w ( M O S predicted ) , E w ( M O S true )) within 0.05 windo ws w along the x-axis. Right: Samples from score-ov er-time animations. V isit goo.gl/cnQbSn to view . T able 2: RMSE and correlation results (reflecting median fold, except as indicated) Baselines AutoMOS Ground-truth Metric / Model Bias-only NNet(utt. length) Raw Quantized a Sample human rating a Utterance-lev el ( n f old = 6000 , 6424 , 6624 , 12348 , 15924 ) RMSE 0.618 0.553 0.462 0.483 0.512 Pearson r − 0.454 0.668 0.638 0.764 Spearman r − 0.399 0.667 0.636 0.757 10 utterance means ( n f old = 600 , 643 , 663 , 1235 , 1593 ) RMSE 0.203 0.213 0.172 0.171 0.358 Pearson r − 0.812 0.930 0.933 0.962 Spearman r − 0.657 0.925 0.925 0.956 Synthesizer-le vel means ( n = 36 ; uses all folds) RMSE 0.252 0.132 0.073 0.075 0.034 Pearson r − 0.795 0.938 0.935 0.987 Spearman r − 0.679 0.949 0.947 0.986 a utterance scores from 1-5 in increments of 0.5 How well can we rank synthesizers relati ve to one another? T o perform this e valuation, we use the abov e fi ve-fold cross validation to predict a MOS for each utterance using the AutoMOS instance from which it was held-out. W e then average at the synthesizer-le vel, giving us a total of 36 E sy nth ( M O S predicted ) , E sy nth ( M O S true ) pairs upon which we e valuate. Results sho wn in T able 2. 3 Discussion AutoMOS tends to av oid very-high or very-low predictions, likely reflecting the distrib ution of the training data. It also seems to learn patterns in the data around certain common "types" of utterances which usually achie ve high ("OK, setting your alarm") or lo w MOS (reading dictionary definitions). It’ s possible that different distrib utions of texts per synthesizer could yield easily predictable differences in synthesizer -MOS. A future improvement would be predicting MOS for the raw te xt and ev aluating the advantage of an utterance relati ve to this baseline. In [ 10 ], naturalness is predictable from unit selection costs; here, we want to remov e the predictiv e baseline of the text. W e hav e begun tuning a TTS engine using AutoMOS. Subsequent human ev aluations will provide concrete results on the model and e valuation criteria we’ ve selected. Similarly , we will experiment with the system for continuous quality testing of a large-scale TTS deployment. It may be possible to lev erage AutoMOS to do stratified sampling of utterances to send to human raters. This would allow raters to focus energy more e venly across the quality spectrum. T o probe what’ s been learned, we hav e explored artificial truncation, as in Figure 2 (right). Methods like layerwise relev ance propagation [ 2 ] or acti vation dif ference propagation [ 15 ] have sho wn promise with image models, and could be interesting to apply to a unit selection cost function. 4 References [1] Alías, F ., Formig a, L., and Llora, X. (2011). Efficient and reliable perceptual weight tuning for unit- selection text-to-speech synthesis based on activ e interactive genetic algorithms: A proof-of-concept. Speech Communication , 53(5):786–800. [2] Binder , A., Bach, S., Monta von, G., Müller , K.-R., and Samek, W . (2016). Layer-wise relev ance propagation for deep neural network architectures. In Information Science and Applications (ICISA) 2016 , pages 913–922. Springer . [3] Grancharov , V ., Zhao, D. Y ., Lindblom, J., and Kleijn, W . B. (2006). Non-intrusiv e speech quality assessment with low computational comple xity . In INTERSPEECH . [4] Hochreiter , S. and Schmidhuber , J. (1997). Long short-term memory . Neural computation , 9(8):1735–1780. [5] Hoshen, Y ., W eiss, R. J., and W ilson, K. W . (2015). Speech acoustic modeling from raw multichannel wa veforms. In 2015 IEEE International Conference on Acoustics, Speech and Signal Pr ocessing (ICASSP) , pages 4624–4628. IEEE. [6] ITU-T (2011). P . 863, Perceptual objectiv e listening quality assessment (POLQA). International T elecom- munication Union, CH-Geneva . [7] Kim, D.-S. (2005). ANIQUE: An auditory model for single-ended speech quality estimation. IEEE T ransactions on Speech and A udio Pr ocessing , 13(5):821–831. [8] Kubichek, R. (1993). Mel-cepstral distance measure for objecti ve speech quality assessment. In Com- munications, Computers and Signal Pr ocessing, 1993., IEEE P acific Rim Confer ence on , volume 1, pages 125–128. IEEE. [9] Malfait, L., Berger , J., and Kastner , M. (2006). P . 563: The ITU-T standard for single-ended speech quality assessment. IEEE T ransactions on A udio, Speech, and Language Pr ocessing , 14(6):1924–1934. [10] Peng, H., Zhao, Y ., and Chu, M. (2002). Perpetually optimizing the cost function for unit selection in a TTS system with one single run of MOS ev aluation. In INTERSPEECH . [11] Pobar , M., Martincic-Ipsic, S., and Ipsic, I. (2012). Optimization of cost function weights for unit selection speech synthesis using speech recognition. Neural Network W orld , 22(5):429. [12] Ribeiro, F ., Florêncio, D., Zhang, C., and Seltzer, M. (2011). Crowdmos: An approach for crowdsourcing mean opinion score studies. In 2011 IEEE International Conference on Acoustics, Speech and Signal Pr ocessing (ICASSP) , pages 2416–2419. IEEE. [13] Rix, A. W ., Beerends, J. G., Hollier, M. P ., and Hekstra, A. P . (2001). Perceptual ev aluation of speech quality (PESQ)-a new method for speech quality assessment of telephone networks and codecs. In Acoustics, Speech, and Signal Pr ocessing, 2001. Pr oceedings.(ICASSP’01). 2001 IEEE International Confer ence on , volume 2, pages 749–752. IEEE. [14] Sainath, T . N., W eiss, R. J., Senior, A., Wilson, K. W ., and V inyals, O. (2015). Learning the speech front-end with raw wa veform CLDNNs. In Pr oc. Interspeech . [15] Shrikumar , A., Greenside, P ., Shcherbina, A., and Kundaje, A. (2016). Not just a black box: Learning important features through propagating acti vation dif ferences. arXiv pr eprint arXiv:1605.01713 . 5
