An Implementable Scheme for Universal Lossy Compression of Discrete Markov Sources

where d : X × X → R + is a single-letter distortion measure. For any R ≥ 0, the minimum achievable distortion (cf. [4] for exact definition of achievability) is characterized as [1], [2], [3] D(X, R) = lim n→∞ min p( Xn |X n ):I(X n ; Xn )≤R

A sequence of codes at rate R is called universal if for every stationary ergodic source X its asymptotic performance converges to D(X, R), i.e.,

For lossless compression where the source is to be recovered without any errors, there already exist well-known implementable universal schemes such as Lempel-Ziv coding [5] or arithmetic coding [6]. In contrast to the situation of lossless compression, for D > 0, there are no well-known practical schemes that universally achieve the rate-distortion curve. In recent years, there has been progress towards designing universal lossy compressor especially in trying to tune some of the existing universal lossless coders to work in the lossy case as well [7], [8], [9]. All of these algorithms are either provably suboptimal, or optimal but with exponential complexity.

Another approach for lossy compression, which is very well-studied in the literature and even implemented in JPEG 2000 image compression standard, is Trellis coded quantization, i.e. Trellis structured code plus Viterbi encoding (c.f. [10], [11] and references therein). This method is in general suboptimal for coding sources that have memory [11]. In [12], an algorithm for fixed-slope Trellis source coding is proposed, and is shown to be able to get arbitrary close to the rate-distortion curve for continuous-valued stationary ergodic sources. The proposed method is efficient in low rate region.

In a recent work [13], a new implementable algorithm for lossy compression of discrete-valued stationary ergodic sources was proposed. Instead of fixing rate (or distortion) and minimizing distortion (or rate), the new algorithm fixes Lagrangian coefficient α, and minimizes R + αD. This is done by assigning energy E(y n ) representing R + αD to each possible reconstruction sequence and finding the sequence that minimizes the cost by simulated annealing. The algorithm starts by letting y n = x n , and at each iteration chooses an index i ∈ {1, . . . , n} uniformly at random, and probabilistically changes y i to some y ∈ X such that there is a positive probability (which goes to zero as the number of iterations increases) that the resulting sequence has higher energy than the original sequence. Allowing the energy to increase especially at initial steps prevents the algorithm from being entrapped in a local minimum. It was shown that using a universal lossless compressor to describe the reconstruction sequence resulting from this process to the decoder results in a scheme which is universal in the limit of many iterations and large block length. The drawback of the proposed scheme is that although its computational complexity per iteration is independent of the block length n and linear in a parameter k n = o(log n), there is no useful bound on the number of iterations required for convergence. In this paper, inspired by the previous method, we propose yet another approach for lossy compression of discrete Markov sources which universally achieves optimum rate-distortion performance for any discrete Markov source. We start by assigning the same cost that was defined for each possible reconstruction sequence in [13]. The cost of each sequence is a linear combination of two terms: its empirical conditional entropy and its distance to the source sequence to be coded. We show that there exists proper linear approximation of the first term such that minimizing the linearized cost results in the same performance as minimizing the original cost. But the advantage is that minimizing the modified cost can be done via Viterbi algorithm in lieu of simulated annealing which was used for minimizing the original cost.

The organization of the paper is as follows. In Section II, we set up the notation, and define the count matrix and empirical conditional entropy of a sequence. Section III describes a new coding scheme for fixed-slope lossy compression which universally achieves the rate-distortion curve for any discrete Markov source and IV describes how to compute the coefficients required by the algorithm outlined in the previous section. Section V explains how Viterbi algorithm can be used for implementing the coding scheme described in Section III. Section VI presents some simulations results, and finally, Section VII concludes the paper with a discussion of some future direc
