Anomalous Communications Detection in IoT Networks Using Sparse Autoencoders Mustafizur R. Shahid ∗ , Gregory Blanc ∗ , Zonghua Zhang † , Herv ´ e Debar ∗ ∗ SAMO V AR, CNRS, T ´ el ´ ecom SudParis, Institut Polytechnique de P aris, France { mustafizur .shahid, gregory .blanc, herve.debar } @telecom-sudparis.eu † SAMO V AR, CNRS, IMT Lille-Douai, Institut Mines-T ´ el ´ ecom, France zonghua.zhang@imt-lille-douai.fr Abstract —Nowadays, IoT devices have been widely deployed for enabling various smart services, such as, smart home or e- healthcare. Ho wever , security r emains as one of the paramount concern as many IoT devices are vulnerable. Moreo ver , IoT malware are constantly evolving and getting more sophisticated. IoT devices are intended to perf orm very specific tasks, so their networking behavior is expected to be reasonably stable and predictable. Any significant beha vioral deviation fr om the normal patterns would indicate anomalous events. In this paper , we present a method to detect anomalous network communications in IoT networks using a set of sparse autoencoders. The proposed approach allo ws us to differentiate malicious communications from legitimate ones. So that, if a device is compromised only malicious communications can be dropped while the service pro vided by the device is not totally interrupted. T o characterize network behavior , bidirectional TCP flows are extracted and described using statistics on the size of the first N packets sent and receiv ed, along with statistics on the corresponding inter- arrival times between packets. A set of sparse autoencoders is then trained to learn the profile of the legitimate communications generated by an experimental smart home network. Depending on the value of N, the developed model achieves attack detection rates ranging from 86.9% to 91.2%, and false positive rates ranging from 0.1% to 0.5%. Index T erms —Machine Learning, Neural Network, Anomaly Detection, Internet of Things, Network Security I . I N T R O DU C T I O N The total number of IoT devices is expected to reach 75 billion by 2030 [1]. This rapid adoption of IoT introduces new security challenges [2] [3] for network administrators. Most IoT devices are vulnerable because of a lack of security experience of the manuf acturer and a short time to market. The devices present man y security flaws, such as weak passwords, backdoors and various software vulnerabilities [4] [5] [6]. Most vulnerabilities are not even properly patched because of a poor software update policy or a lack of security awareness of the end user . From 2016 to 2017, there was a 600 percent increase in IoT attacks [7]. In 2016, Mirai turned thousands of smart de vices into bots. Those infected devices were primarily used to perform DDoS attacks [8]. Mirai performed brute- forcing to infect poorly configured devices. Since Mirai, IoT malware hav e considerably e volv ed and are getting more and more complex. In 2017, the Reaper IoT botnet was mainly exploiting disclosed vulnerabilities to infect devices [9]. In 2018, HideNSeek has become the first IoT malw are capable of surviving a de vice reboot [10]. T o cope with these permanently ev olving threats, new anomaly detection methods need to be dev eloped, especially designed to deal with the huge div ersity of IoT devices. In this context, machine learning can be leveraged to de- velop techniques to detect malicious acti vities in IoT networks. An IoT device is intended to perform very specific tasks that remain the same over time. F or e xample, a smart b ulb can only be switched on or off. Howe ver , it is not supposed to send emails or click on ads, making its beha vior very stable and predictable. On the contrary , the main difficulty encountered in applying data analysis techniques for intrusion detection in the case of general purpose devices, such as desktop computers, laptops or smartphones, is the great v ariability and di versity of the generated network traffic [11]. The versatile nature of the network traffic generated by general purpose devices makes it difficult to define what behavior is supposed to be legitimate. Therefore, anomaly detection methods are, thus, better suited for IoT devices. In this paper , we present a method to detect anomalous communications in IoT networks. Communications detected as being anomalous can be dropped while the legitimate communications are maintained. Such a model, that identifies and blocks only anomalous connections, will allo w a device to provide services even if it is infected by a malware. W e pro- pose to take adv antage of a set of sparse autoencoders to learn the legitimate communication behavior of the IoT network. Due to the great div ersity of IoT devices (camera, smart bulb, motion sensor , etc), the network communications behavior can v ary greatly from one de vice to another . Therefore, one different sparse autoencoder is trained for each IoT device type. Ho wev er, during the testing phase (or actual deployment phase), we assume that it might not be possible to determine what device the network communications belong to. Hence, we feed the network communications data to all the trained sparse autoencoders. A communication is considered to be anomalous if all the trained sparse autoencoders consider so. W e set up an experimental smart home network composed of four IoT de vices to generate legitimate netw ork traf fic data. Bidirectional TCP flows are then extracted. Features used to describe the bidirectional flows are statistics on the size of 978-1-7281-2522-0/19/$31.00 ©2019 IEEE Fig. 1. Sparse Autoencoder the first N packets sent and receiv ed, as well as, statistics on the inter-arri val times between those packets. Depending on the value of N, the developed model achie ves an attack detection rate between 86.9% and 91.2%, and a false positiv e rate between 0.1% and 0.5%. The rest of this paper is organized as follows: Section II describes how to use sparse autoencoders to perform anomaly detection. In Section III, we describe our model and the features that we use. Section IV describes the data used to train and test the model. Then, in Section V we present the experimental results. Section VI revie ws the related works. Finally , Section VII concludes and presents the possible future works. I I . S PA R S E A U TO E N C O D E R S F O R A N O M A LY D E T E C T I O N A. Sparse Autoencoder Autoencoders are unsupervised artificial neural networks that learn to copy their inputs to their outputs under some constraints. The constraints are added at the hidden layer . They force the autoencoder to learn an efficient representation of the input data. Sparsity is such a constraint. In sparse autoencoders [12], the number of neurons in the hidden layer is usually greater than the number of inputs as sho wn in Figure 1. Sparsity is added by forcing the autoencoder to reduce the number of activ e neurons in the hidden layer . A neuron is considered to be acti ve if its output is close to 1 and inactiv e if its output is close to 0. For example, one can constrain the autoencoder to hav e on a verage 1% of significantly active neurons in the hidden layer . T o do so, first, the av erage activ ation of each neurons in the hidden layer is computed. Then neurons that hav e on average an activ ation greater than the targeted activ ation are penalized by adding a sparsity loss term to the cost function. The contribution of the sparsity loss term to the total cost function is controlled through a sparsity weight parameter . The dif ference between the input and the output is called the reconstruction error . Let ˆ x = ( ˆ x 1 , ˆ x 2 , . . . , ˆ x n ) be the output of the autoencoder when fed with a specific input x = ( x 1 , x 2 , . . . , x n ) . Then the reconstruction error RE is giv en by: RE = P ( ˆ x i − x i ) 2 During the training phase, the parameters of an autoencoder are optimized in order to minimize the reconstruction error for a particular dataset. Once trained, if the autoencoder is fed with data that are similar to the data used during the training phase, the reconstruction error will be small. On the contrary , the reconstruction error will be large when test data are dif ferent from the data used during the training phase. B. Detection Thr eshold Determination The reconstruction error RE can be used as a measure of the outlierness of new samples. T o use an autoencoder as an anomaly detector, a detection threshold has to be fixed. The detection threshold is the value of the reconstruction error abov e which an instance is considered as being anomalous. The detection threshold is determined using a validation dataset that is different from the one used for training. The detection threshold thr is calculated as follows: thr = µ ( RE V al ) + σ ( RE V al ) where µ ( RE V al ) is the mean reconstruction error over the validation set and σ ( RE V al ) the corresponding standard deviation. Extreme outliers are remo ved before calculating the detection threshold. Extreme outliers are an y validation sample for which the reconstruction error is greater than tw o times the total number of features ( 2 n ). Indeed, we can pro ve that if the reconstruction error is greater than twice the total number of features then the autoencoder is performing worse than random guessing. Pr oof. Let X i be a random variable that model the distrib ution of the i th feature of the input data. As the data are normalized before being fed to the autoencoder , X i follows a normal distribution centered to 0 and with unit v ariance X i ∼ N (0 , 1) . Let ˆ X i be a random variable that model the i th feature of the output vector . Let us consider that we randomly guess the value of each feature of the output vector from a normal distribution centered to 0 and with unit variance, that is, ˆ X i ∼ N (0 , 1) . Then the error on each indi vidual feature is giv en by: E [( X i − ˆ X i ) 2 ] = V ar ( X i − ˆ X i ) + E [ X i − ˆ X i ] 2 = V ar ( X i ) + V ar ( ˆ X i ) + C ov ( X i , ˆ X i ) + 0 = 2 where E , V ar and C ov stand for the expectation, the variance and the covariance respectiv ely . As the overall reconstruction error is equal to the sum of the error on each feature, we end up with a reconstruction error equal to 2 n . In other words, if we randomly guess the value of each feature of the output v ector from a normal distribution N (0 , 1) , then on average the reconstruction error will be equal to 2 n . I I I . P R O P O SE D M O D E L A. Overview W e propose to detect anomalous communications in IoT networks using a set of sparse autoencoders. Figure 2 shows Fig. 2. Proposed anomalous communications detection architecture using a set of sparse autoencoders (SAE) the proposed architecture. First, network communication data are preprocessed to extract useful features (descibed in Section III-C). The preprocessing step also include features normal- ization. The normalized data is then fed to multiple sparse autoencoders. Indeed, for each IoT device type present in the network, one different sparse autoencoder has been trained to learn its legitimate communication profile. Next, a decision module takes the outputs of all the sparse autoencoders and de- termine whether a communication is anomalous or not. Finally , the role of the mitigation module is to block communications detected as being anomalous. B. Decision Module One different sparse autoencoder is trained to learn the profile of the legitimate communications for each IoT device type present in the network. By IoT de vice type we refer to a device model from a specific manufacturer . W e assume that during the testing phase (or actual deployment phase) it is not possible to know what device is generating the ongoing network communications. Therefore, the data describing each communication are fed to all the trained sparse autoencoders. A communication is considered as being anomalous only if all autoencoders consider so. Formally , let us consider a total of T different IoT device types. Hence, the communication data are fed to T different sparse autoencoders. The reconstruction errors on the output of each autoencoder are calculated and compared to their respective detection thresholds to deter- mine whether the communication is anomalous or not. Let { A 1 ( x ) , A 2 ( x ) , ..., A T ( x ) } be the set of decisions obtained for the T sparse autoencoders when fed with input x , with A i : R n 7→ { 0 , 1 } the decision of the sparse autoencoder trained to learn the legitimate network communication profile of the i th device type. It takes as input a network commu- nication x from the feature space R n and output 0 if the communication is legitimate and 1 if it is anomalous. Note that we assume that for each IoT device type present in the network, there exists an autoencoder that has been trained to learn its legitimate communication profile. Let x be the network communication being tested. It is fed to all the trained sparse autoencoders. The final decision anomal y is given by: anomaly = T T i =1 A i ( x ) where anomaly is equal to 1 if the communication is anomalous. Note that the communication is considered to T ABLE I F E A T U RE S U S ED T O D E SC R I B E B I DI R E C TI O NA L T C P FL O WS Featur es Mean, Median, Min, Max, Standard deviation and Count of the size of the first N packets sent Mean, Median, Min, Max, Standard deviation and Count of the size of the first N packets recei ved Mean and Standard de viation of the IA T between the first N packets sent Mean and Standard de viation of the IA T between the first N packets recei ved be legitimate if at least one autoencoder considers so. The advantage of doing so is that we no longer need to kno w the type of IoT device that generated the network communication beforehand. Indeed, depending on where the detection system is located it can be difficult to find out the type of IoT device that generated the traffic. For example, when the devices communicate through a NA T proxy and the detection system is located outside the local network. C. F eatur es Description Network traffic data are preprocessed in order to extract bidirectional TCP flows identified by their source and des- tination IP addresses and ports. A timeout is used to split long TCP connections into multiple bidirectional flows. The features describing the bidirectional TCP flows are statistics on the size of the first N packets sent and recei ved, along with the corresponding inter -arri val times (IA T). The features are described in T able I. Count stands for the number of packets among the first N packets that have a non-zero size. In other words, it corresponds to the actual number of packets sent or receiv ed. It can be less than N because of the timeout used to split long TCP connections. For example, if the total number of packets sent for the duration of the timeout is equal to some value less than N, then count is equal to that value. Otherwise, it is equal to N. For the IA T to exist, N should be equal or greater than 2. Note that if a communication contains only one packet sent or recei ved, the statistics that cannot be calculated, such as, the mean and standard deviation of the IA T between packets, are all set to 0. The features used to describe the network traf fic are appli- cation agnostic. Any application can run on top of the TCP protocol. Note that the features can be extracted e ven if the network communication is encrypted. The size of packets and IA T have been successfully used in other IoT related works [13] [14] [15]. Our study focuses only on TCP protocols as all the devices used for experiments use HTTP/HTTPS for communications. This makes sense as most of the network communications generated by IoT malware use TCP [7]. Howe ver , the proposed method can be easily e xtended to UDP communications. I V . D A TA S E T D E S C R I P T I O N T o train and test the model, one need three dif ferent datasets: a training set, a validation set and a test set. The training set T ABLE II T OT A L N U M BE R O F B I DI R E C TI O NA L FL OW S P E R D E V IC E Bidirectional flo ws D-Link Motion Sensor 1074 Nest Security Camera 1055 TP-Link Smart Bulb 1040 TP-Link Smart Plug 858 T otal 4027 is used to optimize the parameters also called the weights of the neural network. The validation set is used to fine tune the hyperparameters of the model, namely , the learning rate, the number of epochs used for training (early stopping) and the decision threshold (described in Section II-B). Both the training and v alidation sets only contain legitimate network traffic data as the y are used to learn the normal communication profile. The test set is used to assess the performance of the dev eloped model and it contains both legitimate and malicious network traffic data. A small smart home network is set up to generate legitimate network communications. The experimental smart home con- sists of four IoT devices: a Nest security camera, a D-Link motion sensor, a TP-Link smart bulb and a TP-Link smart plug. Network traffic has been collected for a total of 7 days. T able II shows the total number of bidirectional TCP flows extracted for each de vice. Malicious bidirectional flo ws used in the test set are ob- tained from IoTPOT [16], an IoT honeypot designed to get infected by IoT malware. A total of 46,796 bidirectional TCP flows are extracted from one day of network traffic data. The collected network traf fic data represents network traffic generated by IoT botnets. Note that the number of malicious bidirectional flows is much larger than the number of legitimate ones. This is not an issue as the malicious flows are only used during the testing phase to assess the attack detection rate. V . E V A L U A T I O N A. Experimental Setup As described in Section III-B, one sparse autoencoder per device is trained to learn the legitimate communication profile. The architecture of each sparse autoencoder for our e xperiment is as follows: • The size of the input layer is 16 (equal to the number of features) • The size of the hidden layer is 32 • The target sparsity is equal to 0.1 • The sparsity weight is equal to 0.2 W e train and test the model for dif ferent v alues of N (in- troduced in Section III-C) ranging from 2 to 10. For example, if N is equal to 5, the statistics described in Section III-C, are calculated over the first 5 packets sent and receiv ed. T o get the best out of the limited number of legitimate communication samples, we perform 5-fold cross-validation. That is, the set of collected legitimate communications is split into 5 folds. The sparse autoencoders are trained using 4 folds (that actually consists of the training set and the validation set as described in Section IV) and the remaining fold is used as the test set. The process is repeated 5 times, with each of the 5 folds used exactly once as the test set. B. Achieved P erformance The true positi ve rate (also called recall or attack detection rate) and the false positive rate are used to assess the per- formance of the model. Let T P , T N , F P and F N be the number of true positiv e, true negativ e, false positiv e and false negati ve respectiv ely . The true positiv e rate ( T P R ) and the false positi ve rate ( F P R ) are given by the following formula: T P R = T P T P + F N F P R = F P F P + T N T o assess the performance of the overall model, the test data is fed to all the sparse autoencoders and the final decision is obtained following the method described in Section III-B. Figure 3 shows the achiev ed T P R and F P R for different values of N. T P R oscillates between 86.9% and 91.2%. The T P R reaches the maximum for N equal to 3. That is, looking at more packets than the first 3 packets sent and recei ved no longer improve the T P R . As for the F P R , it ranges from 0.1% to 0.5%, depending on the v alue of N. F P R tends to increase as N goes up. This can be explained by the presence of legitimate samples in the test set that behave more like outliers above a certain value of N. F or example, if the size of the first 6 packets of a communication are stable and in accordance with what was learnt by the model to be le gitimate then it will be correctly classified as being legitimate by any model trained for a value of N less or equal to 6. But if that same communication has the size of its 7th sent packet unduly small or large, then some features such as the mean size of the first 7 packets sent will be greatly affected. As a consequence, models trained for a v alue of N greater than or equal to 7 will misclassify this same communication as being anomalous. Hence, once a legitimate communication has been misclassified as being anomalous by a model trained for a specific value of N, it is very unlikely for that same communication to be correctly classified by a model trained for a greater value of N. This is why F P R tends to increase with N. V I . R E L A T E D W O R K Few works about machine learning for IoT network intru- sion detection exist. In [14], stacked vanilla autoencoders are used to detect compromised de vices in a network. Howe ver , the work does not aim to separate malicious communications from le gitimate ones, b ut only to detect whether or not a de vice is infected. The work presented in [17] takes advantage of the temporal periodicity of traffic generated by IoT devices to detect compromised devices. They use Gated Recurrent Units with a detection threshold. In [18], the authors use an autoencoder to detect anomalies in the data read by the nodes of a W ireless sensor network (WSN). Other works le verage Fig. 3. Achiev ed T P R and F P R for different values of N supervised machine learning. In [19], a set of features is defined to describe MQTT , DNS and HTTP protocols. An AdaBoost ensemble learning algorithm, composed of three dif- ferent machine learning models, is de veloped to detect attacks. In [15], supervised machine learning is used to perform DDoS attack detection in consumer IoT networks. Other works focus on lev eraging machine learning to fingerprint IoT devices in a network [13] [20] [21] [22]. The purpose of IoT device type fingerprinting is to detect de vices that are considered to be vulnerable in order to deny access to the network. V I I . C O N C L U S I O N A N D F U T U R E W O R K S This paper introduced a method to detect anomalous com- munications in IoT networks using a set of sparse autoen- coders. One dif ferent sparse autoencoder is trained to learn the legitimate communication profile of each IoT device type present in the network. The features used are statistics on the size of the first N packets sent and received, along with statistics on the inter-arriv al times between the packets. W e set up an experimental smart home network to assess the performance of our model. Depending on the value of N, our model achiev ed attack detection rates ranging from 86.9% to 91.2% and false positiv e rates ranging from 0.1% to 0.5%. Once a communication is detected as being anomalous it can be dropped without having to totally interrupt the service provided by the de vice. For future w orks, our model should be tested with a network that contains a larger number of IoT devices. One should also consider the case of a general purpose network that contains not only IoT devices but also personal computers or smartphones. Adversarial machine learning can also be lev eraged to assess the robustness of our proposed model. W e are also planning to integrate the de veloped anomaly detection model in a Software Defined Networking (SDN) en vironment in order to provide centralized monitoring and management of multiple IoT networks. R E F E R E N C E S [1] Louis Columbus, “Roundup Of Internet Of Things Forecasts And Market Estimates, 2016, ” https://www .forbes.com/sites/louiscolumbus/2016/11/27/roundup-of- internet-of-things-forecasts-and-market-estimates-2016/. [2] Z. Zhang, M. C. Y . Cho, C. W ang, C. Hsu, C. Chen, and S. Shieh, “Iot security: Ongoing challenges and research opportunities, ” in 2014 IEEE 7th International Conference on Service-Oriented Computing and Applications , 2014. [3] M. A. Khan and K. Salah, “Iot security: Re view , blockchain solutions, and open challenges, ” Futur e Generation Computer Systems , 2018. [4] A. W ang, R. Liang, X. Liu, Y . Zhang, K. Chen, and J. Li, “ An inside look at iot malware, ” in International Conference on Industrial IoT T echnologies and Applications , 2017. [5] OW ASP, “T op 10 IoT V ulnerabilities 2018, ” https://www .owasp.or g/index.php/OW ASP Internet of Things Project. [6] E. Bertino and N. Islam, “Botnets and internet of things security , ” Computer , 2017. [7] Symantec, “Internet Security Threat Report 2018 (ISTR), ” https://www .symantec.com/content/dam/symantec/docs/reports/istr- 23-2018-en.pdf. [8] M. Antonakakis, T . April, M. Bailey , M. Bernhard, E. Bursztein, J. Cochran, Z. Durumeric, J. A. Halderman, L. In vernizzi, M. Kallitsis, D. Kumar , C. Lever , Z. Ma, J. Mason, D. Menscher, C. Seaman, N. Sulliv an, K. Thomas, and Y . Zhou, “Understanding the mirai botnet, ” in Proceedings of the 26th USENIX Confer ence on Security Symposium , ser . SEC’17, 2017. [9] Andy Greenber g, “The Reaper IoT Botnet Has Already Infected a Mil- lion Networks, 2017, ” https://www .wired.com/story/reaper-iot-botnet- infected-million-networks/. [10] Catalin Cimpanu, “”Hide and Seek” Becomes First IoT Botnet Capable of Surviving De vice Reboots, 2018, ” https://www .bleepingcomputer .com/news/security/hide-and-seek- becomes-first-iot-botnet-capable-of-surviving-de vice-reboots/. [11] R. Sommer and V . Paxson, “Outside the closed world: On using machine learning for network intrusion detection, ” in 2010 IEEE Symposium on Security and Privacy , 2010. [12] A. Ng et al. , “Sparse autoencoder , ” CS294A Lecture notes , v ol. 72, no. 2011, pp. 1–19, 2011. [13] M. R. Shahid, G. Blanc, Z. Zhang, and H. Debar, “Iot devices recog- nition through network traffic analysis, ” in 2018 IEEE International Confer ence on Big Data (Big Data) , 2018. [14] Y . Meidan, M. Bohadana, Y . Mathov, Y . Mirsky, A. Shabtai, D. Breiten- bacher , and Y . Elovici, “N-baiot—network-based detection of iot botnet attacks using deep autoencoders, ” IEEE P ervasive Computing , 2018. [15] R. Doshi, N. Apthorpe, and N. Feamster, “Machine learning ddos detection for consumer internet of things de vices, ” in 2018 IEEE Security and Privacy W orkshops (SPW) , 2018. [16] Y . M. P . Pa, S. Suzuki, K. Y oshioka, T . Matsumoto, T . Kasama, and C. Rosso w , “Iotpot: Analysing the rise of iot compromises, ” in 9th USENIX W orkshop on Offensive T echnologies (WOO T 15) , 2015. [17] T . D. Nguyen, S. Marchal, M. Miettinen, M. H. Dang, N. Asokan, and A. Sadeghi, “D ¨ ıot: A crowdsourced self-learning approach for detecting compromised iot devices, ” CoRR , 2018. [Online]. A vailable: http://arxiv .org/abs/1804.07474 [18] T . Luo and S. G. Nagarajany , “Distributed anomaly detection using autoencoder neural networks in wsn for iot, ” in 2018 IEEE International Confer ence on Communications (ICC) , 2018. [19] N. Moustafa, B. T urnbull, and K.-K. R. Choo, “ An ensemble intrusion detection technique based on proposed statistical flow features for protecting network traffic of internet of things, ” IEEE Internet of Things Journal , 2018. [20] M. Miettinen, S. Marchal, I. Hafeez, N. Asokan, A. Sadeghi, and S. T arkoma, “Iot sentinel: Automated de vice-type identification for se- curity enforcement in iot, ” in 2017 IEEE 37th International Conference on Distrib uted Computing Systems (ICDCS) , 2017. [21] Y . Meidan, M. Bohadana, A. Shabtai, M. Ochoa, N. O. T ippenhauer, J. D. Guarnizo, and Y . Elovici, “Detection of unauthorized iot devices using machine learning techniques, ” CoRR , 2017. [Online]. A vailable: http://arxiv .org/abs/1709.04647 [22] Y . Meidan, M. Bohadana, A. Shabtai, J. D. Guarnizo, M. Ochoa, N. O. Tippenhauer , and Y . Elovici, “Profiliot: A machine learning approach for iot device identification based on network traffic analysis, ” in Pr oceedings of the Symposium on Applied Computing , 2017.
