Conditional Generative Adversarial Networks for Speech Enhancement and Noise-Robust Speaker Verification

INTERSPEECH 2017 August 20-24, 2017, Stockholm, Sweden 1 Conditional Generativ e Adversarial Netw orks f or Speech Enhancement and Noise-Rob ust Speaker V erification Daniel Michelsanti and Zheng-Hua T an Department of Electronic Systems, Aalborg Uni v ersity , Denmark dmiche15@student.aau.dk, zt@es.aau.dk Abstract Improving speech system performance in noisy environments remains a challenging task, and speech enhancement (SE) is one of the effecti v e techniques to solve the problem. Moti- vated by the promising results of generative adversarial net- works (GANs) in a variety of image processing tasks, we ex- plore the potential of conditional GANs (cGANs) for SE, and in particular , we make use of the image processing framework proposed by Isola et al. [1] to learn a mapping from the spec- trogram of noisy speech to an enhanced counterpart. The SE cGAN consists of two networks, trained in an adversarial man- ner: a generator that tries to enhance the input noisy spectro- gram, and a discriminator that tries to distinguish between en- hanced spectrograms provided by the generator and clean ones from the database using the noisy spectrogram as a condition. W e evaluate the performance of the cGAN method in terms of perceptual ev aluation of speech quality (PESQ), short-time objectiv e intelligibility (STOI), and equal error rate (EER) of speaker v erification (an example application). Experimental re- sults show that the cGAN method overall outperforms the clas- sical short-time spectral amplitude minimum mean square error (STSA-MMSE) SE algorithm, and is comparable to a deep neu- ral network-based SE approach (DNN-SE). Index T erms : generative adversarial networks, speech en- hancement, speaker verification 1. Intr oduction Dealing with degraded speech signals is a challenging yet im- portant task in many applications, e.g. automatic speaker veri- fication (ASV) [2], speech recognition [3], mobile communica- tions and hearing assistiv e devices [4, 5, 6]. When the receiv er is a human user, the objective of SE is to improve quality and intelligibility of noisy speech signals. When it is an automatic speech system, the goal is to improve the noise-robustness of the system, e.g. to reduce the EERs of an ASV system under adverse conditions. In the past, this problem has been tackled with statistical methods like Wiener filter and STSA-MMSE [7]. Lately , deep learning methods hav e been used, such as DNNs [6, 8], deep autoencoders (DAEs) [5], and con volutional neural networks (CNNs) [9]. Ho we ver , to our knowledge, no one has tried to use GANs for SE yet. GANs are a framework recently introduced by Goodfellow et al. [10], which consists of a generativ e model, or generator (G), and a discriminative model, or discriminator (D), that play a min-max game between each other . In particular, G tries to fool D which is trained to distinguish the output of G from the real data. The architectures used in most of the works today [11] are based on deep con v olutional GAN (DCGAN) [12] that successfully tackles training instability issues when GANs are applied to high resolution images. Three key ideas are used to accomplish this goal. First, batch normalization [13] is applied to most of the layers. Then, the networks are designed to have no pooling layers as done in [14]. Finally , the training is per- formed adopting the Adam optimizer [15]. So far GANs hav e been successfully applied to a variety of computer vision and image processing tasks [1, 12, 16, 17]. Howe ver , their adoption for speech-related tasks is rare with one e xception in [18], in which the authors of the report applied a deep visual analogy network [19] as a generator of a GAN for voice con version, and the results are presented as exam- ple audio files without speech quality or intelligibility or other measures. In a related field, for music, the GAN concept was applied to train a recurrent neural network for classical music generation [20]. V ery recently , a general-purpose cGAN framew ork called Pix2Pix was proposed for image-to-image translation [1]. Mo- tiv ated by its successful deployment on several tasks, we adapt the framework in this work, aiming to explore the potential of cGANs for SE, as part of the overall goal of inv estigating the feasibility and performance of GANs for speech processing. Specifically , we use Pix2Pix to learn a mapping between noisy and clean speech spectrograms as well as to learn a loss function for training the mapping. 2. Pix2Pix framework for speech enhancement In GANs, G represents a mapping function from a random noise vector z to an output sample G ( z ) , ideally indistinguishable from the real data x [10]. In cGANs, both G and D are con- ditioned on some extra information y [1], and they are trained following a min-max g ame with the objectiv e: L ( D , G ) = E x , y ∼ p data ( x , y ) [log( D ( x , y ))]+ E z ∼ p z ( z ) , y ∼ p data ( y ) [log(1 − D ( G ( z , y ) , y ))] . (1) Pix2Pix differs from other cGAN w orks, like [21], because it does not use z . Isola et al. [1] report that adding a Gaussian noise as an input to G, as done in [22], was not effectiv e. Hence, they introduce noise in the form of dropout, but this technique failed to produce stochastic output. Howev er , we are more in- terested in an accurate mapping between a noisy spectrogram and a clean one than a cGAN able to capture the full entropy of the distribution it models, so this represents a minor issue. Figure 1 shows how the data and the condition are used during training in the particular case of this paper . In addition to the adversarial loss L ( D , G ) that is learned from the data, Pix2Pix utilizes also L1 distance between the output of G and the ground truth. The choice of combining different losses, like L2 distance [23] or perceptual losses for a specific task [16, 17], has been shown to be beneficial. In Pix2Pix, L1 distance is preferred to L2 because it encourages less blurring [1] and it tends to generalize better if compared to perceptual losses. INTERSPEECH 2017 August 20-24, 2017, Stockholm, Sweden 2 Figure 1: Generator (G) and discriminator (D) in the Pix2Pix frame work for speech enhancement. G generates an enhanced spectr ogram fr om a noisy input by fooling D, which tries to clas- sify a spectr ogram as clean or enhanced, conditioned on the r espective noisy spectr ogram. Furthermore, G and D, adapted from [12], are a U-Net [24] and a PatchGAN, respectiv ely . Since in image-to-image trans- lation tasks, the input and the output of G share the same struc- ture, G is an encoder-decoder where each feature map of the de- coder layers is concatenated with its mirrored counterpart from the encoder to avoid that the innermost layer represents a bot- tleneck for the information flow . Besides, D is built to model the high frequencies of the data, as the low frequency structure is captured by the L1 loss. This is achiev ed by considering lo- cal image patches. In particular , D is applied conv olutionally across the image to classify each patch as real or fake. Then, the obtained scores are averaged together to get a single output. This architecture has the adv antage of being smaller and can be applied on images of different sizes [1]. When the patch size of D has the same size of the input image, D is equiv alent to a classical GAN discriminator . Our Pix2Pix implementation is based on [25], with G that gets a 256 × 256 1-channel image, while D a 256 × 256 2- channel image. The main differences with the original frame- work are the adoption of 5 × 5 filters in the conv olutional layers, and the last layer of D which is flattened and fed into a single sigmoid output as in [12]. 2.1. Prepr ocessing and training For speech signals with a sample rate of 16 kHz, we computed a time-frequency (T -F) representation using a 512-point short time Fourier transform (STFT) with a hamming window size of 32 ms and a hop size of 16 ms. In this way , the frequency resolution is 16 kHz / 512 = 31.25 Hz per frequency bin. W e considered only the 257-point STFT magnitude vectors which cov er the positiv e frequencies due to symmetry . Our generator G accepts 256 × 256 × 1 input, so for training we concatenated all the speech signals and then split the spectrogram every 256 frames, while for testing we zero-padded the spectrogram of each test sample in order to hav e the number of frames equal to a multiple of 256 and then performed the split accordingly . W e also removed the last row of the spectrogram, which is a choice that has a negligible impact since it represents only the highest 31.25 Hz band of the signal, b ut this allows us to hav e a power -of-2 input size which makes the design of G and D easier . Before the data are fed to our system, they are also normalized to be in the range [ − 1 , 1] . W e trained the GANs using stochastic gradient descent (SGD) and adopting the Adam optimizer, for 10 epochs with a batch size of 1 according to [1], updating G twice per each iteration to avoid a fast con ver gence of D [25]. The networks’ weights hav e been initialized from a normal distribution with zero mean and a standard de viation of 0.02 [1]. The L1 loss has been added to the GAN loss using a scaling factor of 100 [1]. T o enhance a speech signal with Pix2Pix, we first compute the T -F representation of it, and then we forward propagate the spectrogram magnitude through G. Finally , we reconstruct the signal with the in verse STFT using the phase of the noisy input. 3. Experiments 3.1. Evaluation metrics The performance of our system is ev aluated in terms of PESQ [26] (in particular the wide-band extension [27]), STOI [28], and EER of ASV . PESQ and STOI hav e been chosen as they are the most used estimators of speech quality and speech intel- ligibility , respectively . The implementations used in this paper are from [7] for PESQ and from [28] for STOI. Regarding the ASV ev aluation, we use the classical Gaus- sian Mixture Model - Universal Background Model (GMM- UBM) framework [29], which is suitable for short utterances as in this work. W e first built a general model, UBM, which is a GMM trained with an expectation-maximization algorithm using a large amount of speech data not belonging to the target speakers. Then, a target speaker model for each specific pass- phrase and each speaker was derived by maximum a posteriori adaptation of the UBM. The approach of adapting UBM is used in order to have a well-trained model for a speaker even when there is no much data available. At this point, for a test utter- ance we calculate the log likelihood ratio between the claimant speaker model and the UBM. The features extracted from the speech data are 57-dimensional mel-frequency cepstral coeffi- cients (MFCCs), and the GMM mixture number is 512. 3.2. Baseline methods W e compare the results of our approach with other two meth- ods we consider as baselines: STSA-MMSE and an Ideal Ratio Mask (IRM) based DNN-SE algorithms. STSA-MMSE is a statistical-based SE technique, where the a priori signal to noise ratio (SNR) is estimated with the Decision-Directed approach [30] and the noise Power Spectral Density (PSD) is estimated with the noise PSD tracker in [31]. The noise PSD estimate is initialized with the first 1000 samples of each utterance, assumed to be a speech-free region. For the DNN-SE algorithm, we use the same procedure and parameters of [6]. The IRM is estimated by using a DNN with three hidden layers of 1024 units each, and an output layer with 64 units. The input of the DNN is a 1845-dimensional feature vector , which is a robust representation of a frame that combines MFCCs, amplitude modulation spectrogram, relativ e spectral transform - perceptual linear prediction (RAST A-PLP), and gammatone filter bank energies, with their delta and double delta for a context of 2 past and 2 future frames. The training label is represented by the IRM, which is computed as in [32] from the T -F representation based on a gammatone filter bank with 64 filters linearly spaced on a Mel frequency scale and with a bandwidth equal to one equiv alent rectangular bandwidth [33]. The system is trained for 30 epochs with SGD, using the mean square error as error function and a batch size of 1024. In order to enhance a test signal, the DNN provides an estima- tion of the IRM which is applied to the T -F representation of the noisy signal. Finally , the time domain signal is synthesized. INTERSPEECH 2017 August 20-24, 2017, Stockholm, Sweden 3 3.3. Datasets W e use two corpora, TIMIT [34] and RSR2015 [35], as follows: • Set 1 (TIMIT) - 4380 utterances of male speakers are used for UBM training. • Set 2 (RSR2015) - T ext ID from 2 to 30 of sessions 1, 4, and 7 for 50 male speakers (from m051 to m100) are selected to train Pix2Pix and DNN-SE. • Set 3 (RSR2015) - T ext ID 1 of sessions 1, 4, and 7 for 49 male speakers (from m002 to m050) are used to train the speaker models. • Set 4 (RSR2015) - Sessions 2, 3, 5, 6, 8, and 9 of the same text ID and speakers used for training the models, are selected for ev aluation. The choice of RSR2015 as the main database for training and testing can be seen as a compromise, because we were in- terested in the ev aluation of an ASV system, which provides another objecti ve measure of the performance, and RSR2015 is widely used for this task. W e used 5 different noise types to simulate real-life con- ditions: Babble, obtained by adding 6 random speech samples from the Librispeech corpus [36]; white Gaussian noise gen- erated in MA TLAB; Cantine, recorded by the authors; Market and Airplane, collected by F ondazione Ugo Bordoni (FUB) and av ailable on request from the OCT A VE project [37]. Noise data, which were added to the utterances in Set 2, 3, and 4 at different SNR values, used for training and testing are dif ferent. 3.4. Setup Inspired by [2], we in vestigate two different kinds of Pix2Pix- based SE front-ends: 5 noise specific front-ends (NS-Pix2Pix), each of them trained on only one type of noise, and 1 noise general front-end (NG-Pix2Pix), trained on all types of noise. The same has been done for the DNN-SE front-ends, obtaining 5 noise specific front-ends (NS-DNN) and 1 noise general front- end (NG-DNN). For training, we add noise to clean speech at two different SNRs, 10 and 20 dB. With higher SNR it should be easier to train a G able to capture the underlying structure of the noisy input and generate a clean spectrogram, but a test with lower SNRs for training is worth to explore in the future. For testing, results for 5 different SNR conditions are reported: 0, 5, 10, 15, and 20 dB, as is commonly done for ASV , but an interesting future work is to test on lower SNRs, particularly for intelligibility ev aluation. In addition, to find the behavior of the front-ends on noise free conditions, ASV performance on enhanced clean speech data is also reported. In all the tests, the performance of the following front- ends are presented: No enhancement (when no SE algorithm is used on noisy data), STSA-MMSE, NS-DNN, NS-Pix2Pix, NG-DNN, and NG-Pix2Pix. In total, three different tests have been conducted: • T est 1 - In the first test, we compute PESQ and ST OI for the different front-ends to estimate speech quality and intelligibility . • T est 2 - In the second test, the ASV system is trained with enhanced clean speech (except for the No enhancement front-end where clean speech is used) and tested on the 5 types of noise. • T est 3 - The last test is performed to ev aluate the ef- fects of a multi-condition training on ASV . For No en- hancement, STSA-MMSE, NS-DNN, and NS-Pix2Pix the speaker models are built from enhanced clean speech and one kind of enhanced noisy speech, while for NG- DNN and NG-Pix2Pix all kinds of noise are used. 4. Results and Discussion The results of T est 1 are shown in T able 1. It is observed that the av erage PESQ scores of NS-Pix2Pix and NG-Pix2Pix are always better than the other front-ends. The best performance improv ement is achie ved between 5 and 15 dB SNR regardless of the noise type. At 20 dB, our approach outperforms the oth- ers on Market and White noises, but for Airplane noise STSA- MMSE is the best one, while for Babble and Cantine noises the absence of enhancement is superior indicating that all the SE techniques introduce an amount of distortion surpassing the benefit of noise reduction. At 0 dB, NG-Pix2Pix generally out- performs the noise specific version with an exception (Market noise) and its scores are close to DNN-SE ones. In terms of STOI, Pix2Pix front-ends perform similarly to STSA-MMSE. Howe ver , DNN-SE front-ends are superior in al- most all the conditions, ev en though Pix2Pix front-ends achiev e the same or very close results in some situations, e.g. low SNRs for Cantine and Market noises. At 20 dB, we observe the same behavior as the PESQ scores, where the evaluation of not en- hanced signals giv es a better outcome. T able 1: PESQ and STOI performance for the 5 fr ont-ends: No enhancement (a), STSA-MMSE (b), NS-DNN (c), NS-Pix2Pix (d), NG-DNN (e), NG-Pix2Pix (f). PESQ STOI SNR 0 5 10 15 20 mean 0 5 10 15 20 mean Airplane (a) 1.34 1.63 2.02 2.47 3.00 2.09 0.64 0.74 0.82 0.88 0.93 0.80 (b) 1.54 1.79 2.17 2.72 3.26 2.30 0.66 0.74 0.81 0.87 0.91 0.80 (c) 1.65 1.94 2.30 2.73 3.16 2.36 0.69 0.76 0.83 0.88 0.92 0.82 (d) 1.57 2.02 2.51 2.91 3.18 2.44 0.66 0.75 0.81 0.85 0.89 0.79 (e) 1.65 1.94 2.29 2.70 3.14 2.35 0.69 0.76 0.82 0.87 0.91 0.81 (f) 1.67 2.07 2.51 2.88 3.13 2.45 0.67 0.74 0.79 0.83 0.86 0.78 Babble (a) 1.20 1.42 1.79 2.40 3.13 1.99 0.44 0.56 0.67 0.77 0.85 0.66 (b) 1.14 1.31 1.61 2.07 2.65 1.76 0.43 0.56 0.66 0.74 0.81 0.64 (c) 1.25 1.51 1.87 2.31 2.78 1.95 0.50 0.63 0.72 0.79 0.86 0.70 (d) 1.20 1.48 1.98 2.52 2.93 2.02 0.46 0.59 0.71 0.78 0.83 0.67 (e) 1.24 1.52 1.88 2.31 2.78 1.95 0.49 0.62 0.72 0.79 0.85 0.70 (f) 1.20 1.49 2.00 2.53 2.93 2.03 0.46 0.60 0.71 0.77 0.82 0.67 Cantine (a) 1.35 1.65 2.07 2.57 3.30 2.19 0.54 0.66 0.75 0.83 0.90 0.74 (b) 1.38 1.68 2.12 2.67 3.23 2.22 0.55 0.66 0.74 0.82 0.87 0.73 (c) 1.46 1.75 2.15 2.63 3.12 2.22 0.59 0.69 0.76 0.83 0.89 0.75 (d) 1.45 1.84 2.38 2.82 3.13 2.32 0.58 0.68 0.75 0.80 0.85 0.73 (e) 1.47 1.77 2.18 2.64 3.11 2.24 0.60 0.69 0.77 0.83 0.89 0.76 (f) 1.49 1.91 2.43 2.81 3.08 2.34 0.59 0.69 0.75 0.80 0.84 0.73 Market (a) 1.26 1.51 1.89 2.38 3.04 2.02 0.51 0.62 0.73 0.81 0.88 0.71 (b) 1.24 1.45 1.76 2.22 2.79 1.89 0.51 0.62 0.71 0.79 0.85 0.70 (c) 1.35 1.63 2.00 2.46 2.94 2.08 0.56 0.67 0.75 0.82 0.88 0.73 (d) 1.36 1.71 2.21 2.72 3.09 2.22 0.55 0.66 0.74 0.80 0.85 0.72 (e) 1.36 1.63 2.00 2.45 2.93 2.07 0.56 0.67 0.75 0.82 0.88 0.73 (f) 1.35 1.72 2.24 2.68 3.02 2.20 0.56 0.67 0.74 0.79 0.83 0.72 White (a) 1.15 1.31 1.60 2.01 2.57 1.73 0.50 0.61 0.72 0.81 0.89 0.71 (b) 1.35 1.58 1.88 2.25 2.71 1.95 0.53 0.63 0.73 0.81 0.87 0.72 (c) 1.38 1.66 2.00 2.39 2.88 2.06 0.58 0.67 0.75 0.82 0.88 0.74 (d) 1.23 1.54 2.11 2.74 3.14 2.15 0.53 0.64 0.73 0.80 0.86 0.71 (e) 1.35 1.63 1.96 2.29 2.65 1.98 0.57 0.66 0.74 0.81 0.88 0.73 (f) 1.32 1.69 2.22 2.68 3.01 2.19 0.55 0.65 0.73 0.78 0.83 0.71 The ASV performances (T ests 2 and 3) are reported in T a- bles 2 and 3, where the results of the baseline systems are from [38]. For the clean speaker models, Pix2Pix front-ends gener- ally outperform the baseline methods. One exception is seen for Babble noise, where the NG-DNN front-end gives an EER of 8.73%, marginally better than NS-Pix2Pix (8.76%). At low SNR, DNN-SE front-ends sometimes show better results than Pix2Pix, but o verall our approach can be considered superior . On the other hand, the performances of DNN-SE front-ends on multi-condition training are generally better , which presents a substantial improvement if compared with the clean speaker model situation. Our approach is generally better than STSA- MMSE, although the NS-Pix2Pix front-end shows lower per- INTERSPEECH 2017 August 20-24, 2017, Stockholm, Sweden 4 Figure 2: F r om left to right: noisy spectr ogram (White noise at 0 dB SNR); clean spectro gram; spectr ogram of the signal enhanced with NG-Pix2Pix; spectr ogram of the signal enhanced with NG-DNN; spectr ogram of the signal enhanced with STSA-MMSE. T able 2: ASV performance in terms of EER on clean speaker model SNR 0 5 10 15 20 clean mean Airplane No enhancement 21.09 15.99 13.61 11.66 9.18 6.99 13.08 STSA-MMSE 17.69 12.58 8.17 6.53 6.27 5.80 9.51 NS-DNN 16.99 10.55 7.48 6.99 6.15 6.12 9.05 NS-Pix2Pix 17.19 8.84 5.44 5.05 4.63 3.74 7.48 NG-DNN 15.99 8.99 6.12 6.12 5.58 5.67 8.08 NG-Pix2Pix 15.31 7.89 5.58 4.77 4.76 5.44 7.29 Babble No enhancement 19.05 14.63 11.69 11.04 9.18 6.99 12.10 STSA-MMSE 29.04 20.40 12.59 7.82 6.29 5.80 13.66 NS-DNN 17.01 10.54 7.82 6.46 6.12 5.78 8.96 NS-Pix2Pix 18.83 11.22 7.62 5.70 5.10 4.08 8.76 NG-DNN 16.67 10.39 7.50 6.34 5.78 5.67 8.73 NG-Pix2Pix 21.05 13.64 8.50 5.97 4.76 5.44 9.90 Cantine No enhancement 20.72 19.20 14.74 11.81 8.50 6.99 13.66 STSA-MMSE 19.09 12.37 8.16 6.80 6.12 5.80 9.72 NS-DNN 18.71 8.58 6.12 5.49 5.31 5.10 8.22 NS-Pix2Pix 17.33 9.18 5.44 5.10 5.10 4.16 7.72 NG-DNN 19.94 9.18 6.12 5.78 5.44 5.67 8.69 NG-Pix2Pix 17.57 8.84 5.73 5.31 4.76 5.44 7.94 Market No enhancement 29.40 20.07 15.00 11.96 8.93 6.99 15.39 STSA-MMSE 25.51 17.35 11.90 8.28 7.35 5.80 12.70 NS-DNN 21.43 9.86 6.88 6.46 5.78 5.92 9.39 NS-Pix2Pix 17.91 10.33 7.14 5.92 5.17 3.61 8.35 NG-DNN 21.77 10.59 7.48 6.22 5.76 5.67 9.58 NG-Pix2Pix 19.58 11.22 7.48 6.12 5.07 5.44 9.15 White No enhancement 45.90 43.20 34.61 26.28 16.91 6.99 28.98 STSA-MMSE 30.95 21.17 13.95 10.20 8.50 5.80 15.10 NS-DNN 39.46 20.75 9.86 7.82 6.12 6.02 15.01 NS-Pix2Pix 40.48 28.23 12.45 7.86 6.46 6.46 16.99 NG-DNN 40.14 21.77 10.88 8.16 6.80 5.67 15.57 NG-Pix2Pix 30.61 17.33 9.40 7.14 5.78 5.44 12.62 formance when it deals with white noise. In general, Pix2Pix can be considered competiti ve with DNN-SE (better PESQ and EER on the clean speaker models, but worse STOI and EER for multi-condition training) and o ver - all superior to STSA-MMSE. Figure 2 shows the spectrograms of a noisy utterance (White noise at 0 dB SNR), together with its clean and enhanced versions with NG-Pix2Pix, NG-DNN, and STSA-MMSE. It is observed that the spectrogram enhanced by the cGAN approach preserves the structure of the original signal better than the other SE techniques, while at the same time more noises remain es- pecially at high frequency regions, as compared with NG-DNN. The spectrogram enhanced by STSA-MMSE is snowy all over the places. 5. Conclusion In this paper we in vestigated the use of conditional genera- tiv e adversarial networks (cGANs) for speech enhancement. W e adapted the Pix2Pix frame work, intended to solve generic image-to-image translation problems, and ev aluated the perfor- mance of this approach in terms of estimated speech percep- tual quality and speech intelligibility , together with equal er- ror rate of a Gaussian Mixture Model - Universal Background T able 3: ASV performance in terms of EER on multi-condition speaker model SNR 0 5 10 15 20 clean mean Airplane No enhancement 32.28 26.87 21.10 16.38 9.86 5.83 18.72 STSA-MMSE 25.51 15.48 8.16 6.12 5.44 5.44 11.03 NS-DNN 14.78 8.26 5.44 5.53 4.76 4.76 7.26 NS-Pix2Pix 16.67 7.14 5.10 4.03 3.78 4.42 6.86 NG-DNN 11.38 6.12 4.78 4.72 4.23 4.00 5.87 NG-Pix2Pix 13.27 6.43 5.78 5.44 5.27 4.78 6.83 Babble No enhancement 21.77 15.37 11.93 9.52 8.16 6.12 12.15 STSA-MMSE 33.50 23.13 16.23 12.63 8.84 7.12 16.91 NS-DNN 16.26 9.52 6.99 6.08 5.78 5.17 8.30 NS-Pix2Pix 20.75 10.88 6.12 4.76 4.08 4.36 8.49 NG-DNN 16.00 9.18 5.44 4.76 4.08 4.00 7.19 NG-Pix2Pix 21.72 12.44 6.46 5.34 5.22 4.78 9.33 Cantine No enhancement 24.11 17.22 12.93 10.88 9.18 7.48 13.63 STSA-MMSE 19.05 12.59 8.21 6.91 6.12 6.32 9.87 NS-DNN 12.93 5.91 4.42 4.25 4.27 3.78 5.93 NS-Pix2Pix 14.29 6.87 4.76 4.00 4.08 4.76 6.46 NG-DNN 11.61 5.78 5.10 4.57 4.08 4.00 5.86 NG-Pix2Pix 14.10 7.48 5.44 5.44 5.27 4.78 7.08 Market No enhancement 36.05 26.06 18.37 13.32 9.18 5.44 18.07 STSA-MMSE 29.25 21.07 13.95 10.98 7.82 6.67 14.97 NS-DNN 19.33 8.16 6.24 5.41 4.53 4.29 7.99 NS-Pix2Pix 18.49 9.18 5.82 4.42 3.74 4.76 7.74 NG-DNN 18.37 8.16 5.78 4.44 4.42 4.00 7.53 NG-Pix2Pix 19.30 9.37 6.37 5.44 5.10 4.78 8.39 White No enhancement 35.88 24.40 18.37 15.81 14.97 5.85 19.21 STSA-MMSE 30.95 20.07 7.48 6.46 6.46 4.76 12.70 NS-DNN 27.21 9.52 6.12 5.02 4.65 5.78 9.72 NS-Pix2Pix 39.37 23.81 10.20 6.46 5.95 6.44 15.37 NG-DNN 26.19 11.22 7.14 5.10 4.08 4.00 9.62 NG-Pix2Pix 30.41 14.29 8.84 6.60 5.78 4.78 11.78 Model based speaker verification system. The results we ob- tained allow us to conclude that cGANs are a promising tech- nique for speech denoising, being globally superior to the clas- sical STSA-MMSE algorithm, and comparable to a DNN-SE algorithm. Future work includes a more extensiv e ev aluation of the framew ork in more critical SNR situations, and modifications aiming at making it specific for the task. For example, a model with G generating a small size output window from a fixed num- ber of successive frames can be built as it is often done in deep neural networks for speech processing, and a specific perceptual loss to be added to the cGAN loss can be designed. 6. Acknowledgements The authors w ould like to thank Hong Y u for pro viding data and speaker v erification results for the baseline systems and Morten K olbæk for his assistance and softw are used for the speaker ver - ification and DNN speech enhancement baseline systems. This work is partly supported by the Horizon 2020 OC- T A VE Project (#647850), funded by the Research European Agency (REA) of the European Commission, and the iSocioBot project, funded by the Danish Council for Independent Re- search - T echnology and Production Sciences (#1335-00162). INTERSPEECH 2017 August 20-24, 2017, Stockholm, Sweden 5 7. References [1] P . Isola, J.-Y . Zhu, T . Zhou, and A. A. Efros, “Image-to-image translation with conditional adversarial networks, ” arXiv pr eprint arXiv:1611.07004 , 2016. [2] M. K olbœk, Z.-H. T an, and J. Jensen, “Speech enhancement us- ing long short-term memory based recurrent neural networks for noise robust speaker verification, ” in Spoken Language T echnol- ogy W orkshop (SLT), 2016 IEEE . IEEE, 2016, pp. 305–311. [3] M. L. Seltzer , D. Y u, and Y . W ang, “ An inv estigation of deep neural networks for noise robust speech recognition, ” in Acous- tics, Speech and Signal Processing (ICASSP), 2013 IEEE Inter- national Confer ence on . IEEE, 2013, pp. 7398–7402. [4] J. Chen, Y . W ang, S. E. Y oho, D. W ang, and E. W . Healy , “Large-scale training to increase speech intelligibility for hearing- impaired listeners in novel noises, ” The Journal of the Acoustical Society of America , vol. 139, no. 5, pp. 2604–2612, 2016. [5] X. Lu, Y . Tsao, S. Matsuda, and C. Hori, “Speech enhancement based on deep denoising autoencoder, ” in Interspeec h , 2013, pp. 436–440. [6] M. K olbæk, Z.-H. T an, and J. Jensen, “Speech intelligibility potential of general and specialized deep neural network based speech enhancement systems, ” IEEE/ACM T ransactions on Au- dio, Speech, and Language Processing , vol. 25, no. 1, pp. 153– 167, 2017. [7] P . C. Loizou, Speech enhancement: theory and practice . CRC press, 2013. [8] Y . Xu, J. Du, L.-R. Dai, and C.-H. Lee, “ A regression ap- proach to speech enhancement based on deep neural networks, ” IEEE/ACM T ransactions on Audio, Speech and Language Pro- cessing (T ASLP) , vol. 23, no. 1, pp. 7–19, 2015. [9] S. R. Park and J. Lee, “ A fully conv olutional neural network for speech enhancement, ” arXiv preprint , 2016. [10] I. Goodfellow , J. Pouget-Abadie, M. Mirza, B. Xu, D. W arde- Farley , S. Ozair , A. Courville, and Y . Bengio, “Generative adver - sarial nets, ” in Advances in neural information pr ocessing sys- tems , 2014, pp. 2672–2680. [11] I. Goodfellow , “Nips 2016 tutorial: Generative adversarial net- works, ” arXiv pr eprint arXiv:1701.00160 , 2016. [12] A. Radford, L. Metz, and S. Chintala, “Unsupervised representa- tion learning with deep con volutional generativ e adversarial net- works, ” arXiv pr eprint arXiv:1511.06434 , 2015. [13] S. Iof fe and C. Szegedy , “Batch normalization: Accelerating deep network training by reducing internal covariate shift, ” arXiv pr eprint arXiv:1502.03167 , 2015. [14] J. T . Springenberg, A. Dosovitskiy , T . Brox, and M. Riedmiller, “Striving for simplicity: The all con volutional net, ” arXiv preprint arXiv:1412.6806 , 2014. [15] D. Kingma and J. Ba, “ Adam: A method for stochastic optimiza- tion, ” arXiv preprint , 2014. [16] C. Ledig, L. Theis, F . Husz ´ ar , J. Caballero, A. Cunningham, A. Acosta, A. Aitken, A. T ejani, J. T otz, Z. W ang et al. , “Photo- realistic single image super-resolution using a generativ e adver- sarial network, ” arXiv pr eprint arXiv:1609.04802 , 2016. [17] H. Zhang, V . Sindagi, and V . M. Patel, “Image de-raining us- ing a conditional generativ e adversarial network, ” arXiv preprint arXiv:1701.05957 , 2017. [18] S. Mobin and J. Bruna, “V oice con version using con volutional neural networks, ” arXiv pr eprint arXiv:1610.08927 , 2016. [19] S. E. Reed, Y . Zhang, Y . Zhang, and H. Lee, “Deep visual analogy-making, ” in Advances in Neural Information Processing Systems , 2015, pp. 1252–1260. [20] O. Mogren, “C-rnn-gan: Continuous recurrent neural networks with adversarial training, ” arXiv preprint , 2016. [21] M. Mirza and S. Osindero, “Conditional generative adversarial nets, ” arXiv preprint , 2014. [22] X. W ang and A. Gupta, “Generative image modeling using style and structure adversarial networks, ” in Eur opean Conference on Computer V ision . Springer , 2016, pp. 318–335. [23] D. P athak, P . Krahenb uhl, J. Donahue, T . Darrell, and A. A. Efros, “Context encoders: Feature learning by inpainting, ” in Proceed- ings of the IEEE Conference on Computer V ision and P attern Recognition , 2016, pp. 2536–2544. [24] O. Ronneberger , P . Fischer , and T . Brox, “U-net: Conv olutional networks for biomedical image segmentation, ” in International Confer ence on Medical Image Computing and Computer-Assisted Intervention . Springer, 2015, pp. 234–241. [25] Y .-C. Lin, “pix2pix-tensorflow , ” Github repository: https://github .com/yenchenlin/pix2pix-tensorflow , 2016, ac- cessed: March 2017. [26] A. W . Rix, J. G. Beerends, M. P . Hollier, and A. P . Hek- stra, “Perceptual ev aluation of speech quality (pesq)-a new method for speech quality assessment of telephone networks and codecs, ” in Acoustics, Speech, and Signal Processing , 2001. Pr o- ceedings.(ICASSP’01). 2001 IEEE International Conference on , vol. 2. IEEE, 2001, pp. 749–752. [27] ITU, “Wideband extension to recommendation p.862 for the as- sessment of wideband telephone networks and speech codecs, ” A vailable: https://www .itu.int/rec/T -REC-P .862.2-200511-S/en, 2005, accessed: March 2017. [28] C. H. T aal, R. C. Hendriks, R. Heusdens, and J. Jensen, “ An al- gorithm for intelligibility prediction of time–frequency weighted noisy speech, ” IEEE T ransactions on Audio, Speech, and Lan- guage Pr ocessing , vol. 19, no. 7, pp. 2125–2136, 2011. [29] A. K. Sarkar and Z.-H. T an, “T ext dependent speaker verification using un-supervised hmm-ubm and temporal gmm-ubm, ” Pr o- ceedings of INTERSPEECH (to appear) , 2016. [30] Y . Ephraim and D. Malah, “Speech enhancement using a minimum-mean square error short-time spectral amplitude esti- mator , ” IEEE T ransactions on Acoustics, Speec h, and Signal Pr o- cessing , vol. 32, no. 6, pp. 1109–1121, 1984. [31] R. C. Hendriks, R. Heusdens, and J. Jensen, “Mmse based noise psd tracking with low complexity , ” in Acoustics Speech and Sig- nal Pr ocessing (ICASSP), 2010 IEEE International Conference on . IEEE, 2010, pp. 4266–4269. [32] Y . W ang, A. Narayanan, and D. W ang, “On training targets for supervised speech separation, ” IEEE/ACM T ransactions on Au- dio, Speech and Language Pr ocessing (T ASLP) , vol. 22, no. 12, pp. 1849–1858, 2014. [33] D. W ang and G. J. Brown, Computational auditory scene analy- sis: Principles, algorithms, and applications . W iley-IEEE Press, 2006. [34] J. S. Garofolo, L. F . Lamel, W . M. Fisher, J. G. Fiscus, and D. S. Pallett, “Darpa timit acoustic-phonetic continous speech corpus cd-rom. nist speech disc 1-1.1, ” NASA STI/Recon technical r eport n , vol. 93, 1993. [35] A. Larcher , K. A. Lee, B. Ma, and H. Li, “T ext-dependent speak er verification: Classifiers, databases and rsr2015, ” Speech Commu- nication , vol. 60, pp. 56–77, 2014. [36] V . Panayoto v , G. Chen, D. Povey , and S. Khudanpur, “Lib- rispeech: an asr corpus based on public domain audio books, ” in Acoustics, Speech and Signal Pr ocessing (ICASSP), 2015 IEEE International Confer ence on . IEEE, 2015, pp. 5206–5210. [37] M. Falcone, B. Fauve, M. Cornacchia et al. , “Corpora collection, ” OCT A VE (Objective Contr ol of TAlk er VErification), Deliverable 17 , 2016. [38] H. Y u, Z.-H. T an, Z. Ma, and J. Guo, “ Adversarial network bottle- neck features for noise robust speaker verification, ” Proceedings of INTERSPEECH (to appear) , 2017.
